| BRAND | Steimel |
| Product | ASF3/50RD-112451R |
| Description | Pumpenaggregat |
| Internal code | ONR196342 |
| Weight | 1 |
| Technical specification | A-SF3/50RD-VLFM, Pumpenaggregat, 2-18 bar 4,0 KW, IE2, 1500, 230/400V, 50HZ, IP55, F, B5 Materialnummer : 000.001.153.090 Zahnradpumpenaggregat : SF 3/50 RD - VLFM Artikel-Nr. : ASF3/50RD-112451R Maßblatt : DPA053D-112LFM-R31 Ersatzteilliste : DET053050RD--165 Saug- u. Druckanschluss : SAE 1 1/2 Gehäuseteile : EN-GJL-250 (GG-25) Ritzelwellen, geräuschopti. : 16MnCrS5, egh., schrägverzahnt Lagerung : Mehrschicht Wellenabdichtung : Radialwellendichtring Elastomere : FKM Fördermedium : Schmieröl Viskosität : 50-5000 cSt Temperatur : 10-60°C Fördermenge : ca. 70,8 / 84,9 l/min Druck : 5 bar Drehzahl : 1450 / 1740 1/min Druckbegrenzungsventil Einstellbereich : 2-18 bar Öffnungsdruck : 8 bar Drehrichtung : rechts Probelauf : ja, mit HLPD 46 Kupplung : BKUA055-1928-301 Pumpenträger mit Fuß : BLF053250128LA21 Drehstrommotor : LDM112-04-901 Motordaten: Leistung 1/2 : 4,0 / 4,6 kW Drehzahl 1/2 : 1500 / 1800 1/min Spannung 1 : 230/400 Volt bei 50 Hz Spannung 2 : 265/460 Volt bei 60 Hz Effizienzklasse : IE2 Zusatzschild (ohne IE2) für: Spannung : 220-240/380-420 Volt bei 50/60 Hz : 250-280/440-480 Volt bei 60 Hz Schutzart : IP 55 Isolierstoffklasse : F Bauform : B 5 Anstrich : grundiert HDO058 Typenschild : ETY924-D/E--PE02 wie unter PU120389 geliefert statistische Warennummer:84136039 Gewicht: ca. 51 kg/Stück Ursprungsland: Deutschland Gefahrgut: nein |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF3/50RD-112451R Pumpenaggregat number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
