| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2P4702EBBA |
| Description | . |
| Internal code | ONR1489754 |
| Weight | 2.5 |
| Custom code | 84136031 |
| Technical specification | 010-250-01300 XV2P / 11D-1 / 2-1 / 2 10.8ccm / rev - clockwise - 260bar External gear pump size 2 with aluminum body and aluminum flanges Delivery volume: 10.8 ccm / rev Direction of rotation: clockwise Mounting flange: Fitting Ø 36.5 mm - 4 hole fastening 96.2 mm x 71.5 mm - Ø 9 mm Drive shaft: conical 1: 8 - woodruff 4 mm Suction connection: G 1/2 " Pressure connection: G 1/2 " Installation length: 98.2 mm Sealing material: NBR Permissible shaft torque: 233.2 Nm Continuous pressure limited by the drive shaft: 260 bar Continuous pressure: 260 bar Peak pressure (max. 0.5 sec.): 300 bar Minimum speed: 700 rpm Maximum speed: 3500 rpm |
Please Contact Us to Order to offer competitive prices and delivery time for Vivoil Oleodinamica Vivolo - X2P4702EBBA . number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
