| BRAND | Ortlinghaus |
| Product | 0023-000-63-190046 |
| Internal code | ONR4195405 |
| Custom code | 84836080 |
| Technical specification | hydraulically operated clutch/brake combination Clutch torque Ts 2,500.0 Nm Braking torque Td 1,000.0 Nm Operating pressure pcl 60.0 bar max. perl Pressure overrun 5.0 bar Back pressure pbs 24.0 bar Carrier design, bore with feather key Ø beam hole 75,000 mm Bore fit H7 Groove two grooves 180° offset Slot Width Carrier Groove 20.00 mm Fitting groove width support groove P9 Slot depth support groove 4.90 mm Fitting Slot Depth Carrier Groove +0.2 Housing shape coupling, pot housing, narrow wall. Outer contour pot. Coupling With Centring Seat Øhousing bore clutch 118,000 mm Housing shape brake flange housing open CE marking with CE marking Scope of CE Documentation Complete Documentation Language of Documentation German |
Discover the superior quality and performance of the Ortlinghaus 0023-000-63-190046 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 0023-000-63-190046 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 0023-000-63-190046 :
At Onrion LLC , we offer the 0023-000-63-190046 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 0023-000-63-190046 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ortlinghaus products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Original Ortlinghaus
ABTREIBSMOMENT MAX: 63000 Nm ABTREIBSDREHZAHL MAX: 100 1 / min
Air Coupling
HS-CODE: 84839089
hydraulic accumulator
Öleinführung
VALVE, PRESS SAFETY
Press Safety Valve
Pressensicherheitsventil
hydraulic progressive control
CLUTCH/BRAKE
Original Ortlinghaus oil inlet 2 channels Number of channels 2 Port size G 3/4
2 channel oil inleed
Original Ortlinghaus oil inlet 3 channels
AIR Inlet Adaptor version II
mechanically actuated sine-disk clutch
mechanically actuated sine-disk clutch
mechanically actuated sine-disk clutch
GROUPS brake- clutch
hydraulically operated clutch-brake combination
hydraulically actuated clutch-brake combination Fit carrier bore AFTER YOUR INFORMATION CE marked with CE marking Scope of CE documentation complete documentation The German language documentation Shape clutch housing pot narrow wall Shape brake flange open Girder bore with keyway Commodity Code: 84836080
