| BRAND | Burkert |
| Product | 00296425 |
| Description | 3/2-and 5/2-way pneumatic valve 32mm |
| Internal code | ONR4033476 |
| Custom code | 84812090 |
| Technical specification | 6519-W06,0-NM82-FS05-B5-024/DC-02 * HA15+MT66+NA38+PU01 Type 6519 6519 Mode of operation W Either 5/2 or 3/2 way Nominal size 06.0 6 mm Line connection 1 NM82 NPT 1/4 socket Line connection 2 FS05 flange pattern on the side Namur flange Actuation type B electropneumatic / air spring + mech. feather Spool size 5 32 mm Voltage 024 24 volts Frequency DC direct current Power consumption 02 2 watts Special feature HA15 manual operation with screw slot, material as housing MT66 precontrol from MS NA38 Coil material, insulation class H PU01 UL recognized for USA and Canada cURus Pressure min 2 bar Pressure max 8 bar QNN 900 l / min Medium temp. min -10 ° C Medium temp. max 50 ° C Ambient temp. min -25 ° C Ambient temp. max 55 ° C |
Discover the superior quality and performance of the Burkert 00296425 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 00296425 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 00296425 :
At Onrion LLC , we offer the 00296425 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 00296425 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
