BRAND | Wika |
Product | 14325569 |
Description | Differential pressure gauge |
Internal code | ONR4021983 |
Technical specification | Model DPGS40 Nominal size Differential pressure indication: Ø 100 mm Working pressure indication: Ø 22 mm Accuracy Differential pressure indication: ≤ 2.5 % of span (option ≤ 1.6 %) Working pressure indication: ≤ 4 % of span Scale ranges (EN 837) Differential pressure: 0 ... 0.25 to 0 ... 10 bar Working pressure: 0 ... 25 bar Max. working pressure (stat.) 25 bar Overpressure safety Either side max. 25 bar Permissible temperature Ambient: -10 ... +70 °C Medium: -10 ... +90 °C Storage: -40 ... +70 °C Ingress protection IP65 per IEC/EN 60529 Media chamber (wetted) Aluminium, EN AC–Al Si9Cu3(Fe), black lacquered (option: Stainless steel 1.4571) Process connections (wetted) 2 x G 1/4 female, lower mount, in-line, centre distance 26 mm Pressure elements (wetted) Differential pressure: Compression springs from stainless steel 1.4310 and separating diaphragm from FPM/FKM (option: NBR) Working pressure: Bourdon tube from Cu-alloy Transmission parts (wetted) Stainless steel 1.4301, 1.4305, 1.4310, FPM/FKM (option: NBR) Sealings (wetted) FPM/FKM (option: NBR) Movement Copper alloy Dial Differential and working pressure indication: White dial, black lettering Pointer Differential and working pressure indication: Blue pointer Zero adjustment for differential pressure indication Via screw in the dial Case Aluminium, EN AC–Al Si9Cu3(Fe), black lacquered Window Plastic, with plug screw for zero and switch point adjustment Weight approx. 1.4 kg |
Discover the superior quality and performance of the Wika 14325569 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 14325569 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 14325569 :
At Onrion LLC , we offer the 14325569 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 14325569 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
