Discover the superior quality and performance of the Stahl 247671 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 247671 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 247671 :
At Onrion LLC , we offer the 247671 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 247671 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
(Light fitting for fluorescent lamps explosion-protected Type : 6600/542-8010-2230 Enclosure material : Polyester resin Lamp cover material : Polycarbonate Number of lamps : 2 Lamp wattage : 36 W Rated operational voltage AC : 240 V Rated operational voltage DC : 254 V Application range (Zone) : 2 , 21, 22 Gas explosion protection : II 3 G Ex nA IIC T4 Dust explosion protection : II 2 D Ex tb IIIC 80 °C Min. ambient temperature : -25 °C Max. ambient temperature : +55 °C Type of protection (IP) : IP66 Through wiring : without Connection : 1 x M25 x 1,5 Plug : 2 x M25 x 1,5 CCT No.: 94054035 DE Net weigth: 5,000 KG)
(MontageschieneZubehoer)
(WandbefestigungswinkelZubehoer)
8003 / 131-008-2-r-MS1 key switch SS cage clamp command button / switch for panel mounting Series 8003, explosion-proof: key switch, 8003/1 008-2 Locking ..-: Standard connection: spring terminals with terminal chamber contacts: NO / NO contact material : silver-nickel switching position: 2 positions, latching use in: zones 1 & 2, 21 & 22
LED Indicating Lamp for panel mounting explosion-protected Type Rated operational voltage AC : 254 V Enclosure material : Polyamide Luminous colour : blue green red white yellow Version : with connection chamber Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex de mb IIC T6 Min. ambient temperature : -30 °C Max. ambient temperature : +55 °C Type of protection (IP) : IP65 Electric service life : 10.000 lighting hours CCT No.: 85318095 DE Net weigth: 0,130 KG
8030 / 51-033 installation switch 2-pole switch, Rated operating voltage: 250 V DC / 690 V AC
Installation switch, 2-pol, ON-OFF Installationsschalter Reihe 8030/51, explosion protected Version: OFF switch Number of poles: 2-pole Material Enclosure: Polyester Cover: Polyamide For use in: Zones 1 & 2, 21 & 22 CCT No.: 85365080 DE Net weigth: 0,600 KG
8030 / 51-035 installation switch 2-pole switch, Rated operating voltage: 250 V DC / 690 V AC
Control device system Series ConSig 8040 explosion-protected Type : 8040/1180X-10L07BA05 Rated operational voltage AC : 550 V Rated operational current : 10 A Enclosure material : Polyester resin Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex de IIC T6 Dust explosion protection : II 2 D Ex tD A21 80 °C Min. ambient temperature : -20 °C Max. ambient temperature : +40 °C Type of protection (IP) : IP66 Installation position middle : EM-STOP stay-put button red - (turning arrow) with standard seal Built-in element middle : Contact element Switching arrangements middle : NC / NO Cable entry bottom : 1 x M25 Ø 7 ... 17 mm Flanges and plates : without flange, without plate
8040 / 1280x-01L13BA05-01L08BA05 Command / signaling device
8040 / 1280x-01L13BA02-01L08BA01 Command / signaling device pushbutton
(8080 / 1-2 NO / NC Contact element SPARE PART snap-action contact with spring corresponds to your part no. 132528)
8082 / 1-1-00 break contact element screw command row of buttons 8082 explosion protected, Connection: Screw Contacts: 1 NC Contact Material: Silver Nickel For use in: Zones 1 & 2
8082 / 1-2-00 normally open contact element screw command row of buttons 8082 explosion protected, Connection: Screw Contacts: 1 NO Contact Material: Silver Nickel For use in: Zones 1 & 2
8102/21-32-C995 Junction Box
8118/122-199 Terminal box Ex e
8146/5052-C796 alarm and fire alarm with mushroom put button
control box Type: 8146/5041 Technical specifications: Gas - Explosion protection: Ex II 2 G Ex de IIC T6 Gb Dust - Explosion protection: Ex II 2 D Ex tb IIIC T80 ° C Db IP66 Test Certificate ATEX: PTB 01 ATEX 1024 Test certificate IECEX: IECEx PTB 06.0090 Material: Polyester resin Dimensions: 112 x 170 x 91 mm IP 66 Ambient temperature: -20 ° C ... + 40 ° C Rated voltage: 230 V / 50 Hz Rated current: 6 A Control voltage: V / Hz Schematic: Without wiring Other Approval: on request 1 ST Pilzschluesseltaster EMERGENCY STOP MS 1 Contact element Oe + S 1 ST protective conductor terminal USLKG 5 1 ST: Lower 8161/5 M20-13-fitting M20x1,5sw
Blanking Plug
(nut M16 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M16 x 1.5 Width across flats [mm]: 19 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,135 KG)
nut M20x1.5
Blanking Plug
(nut M25 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M25 x 1.5 Width across flats [mm]: 29 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,348 KG)
(blanking plugs f. cable glands Pg9 /M16.....50pcs CCT No.: 39269097 DE Net weigth: 0,061 KG)
(blanking plugs f. multiple cable glands, d 5,5mm...50pcs CCT No.: 39269097 DE Net weigth: 0,031 KG)
Cable gland with reduction sealing insert explosion-protected
8161/5-M16-9 Cable gland Ex e polyamide, 4-9mm, 50 pcs Cable Glands Series 8161, explosion protected Version: 8161/5 Ex e (black) Thread size: M16 x 1.5 Number of entries: 1 Cable dia. range [mm]: 4 ... 9 For use in: Zones 1 & 2, 21 & 22
(Cable Glandsexplosion-protectedType : 8161/5-M25-17Thread size : M25Thread length : 10 mmMaterial : PolyamideColour : blackClamping range : 7 ... 17 mm2Cable armour : Unarmoured cablesApplication range (Zone) : 1 , 2 , 21 , 22Type of protection (IP) : IP66Gas explosion protection : II 2 G Ex e IIDust explosion protection : II 2 D Ex tD A21Min. ambient temperature : -40 °CMax. ambient temperature : +75 °CCCT No.: 39269097 DENet weigth: 0,020 KG)
(Stopping Plug explosion-protected Type : 8290/3-M25 Material : Polyamide Thread size : M25 Drive : Hexagon socket Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e IIC Gb Dust explosion protection : II 2 D Ex tb IIIC Db Min. ambient temperature : -60 °C Max. ambient temperature : +80 °C Packaging unit : 100 CCT No.: 85389099 DE Net weigth: 0,700 KG)
