| BRAND | Pietro Fiorentini |
| Product | 250M3 /21MBAR |
| Description | position of gas expansion |
| Internal code | ONR92919 |
| Weight | 1 |
Discover the superior quality and performance of the Pietro Fiorentini 250M3 /21MBAR with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 250M3 /21MBAR is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 250M3 /21MBAR :
At Onrion LLC , we offer the 250M3 /21MBAR at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 250M3 /21MBAR ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Pietro Fiorentini products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
position of gas expansion
7013402GD REVAL 182/G ANSI 150 DN 50
Gas pressure regulator with power, self-operated, fail to close, ANSI 150, CE tested according to PED 97/23 / EC module B and EN334, actuator sleeve valve actuator housing GGG40, Ps 16 bar according to EN12186, Pa 6 mbar to 12 bar, Design temperature -20 ° C / + 60 ° C, Operating EN334 -10 (-20) ° C / + 60 ° C, lacquering Actuator housing color: RAL9006, flange galvanized, plastic coated actuator internal Piping I / O 10L, pulse and respiration terminals 12L KG 2335, length 254mm, weight incl. Pilot system 50kg
Rate (of 2) Screw- Model Steel / Alu
Rate (of 2) Screw- Model Steel / Alu
APERFLUX 851 ANSI600RF DN 150 7015762
Gas pressure regulator with power, self-operated, fail to open, flanges ANSI600RF, CE approved according to PED 97/23 / EC module B, EN334 and DIN3381, actuator Flat diaphragm, easy to maintain, actuator housing A352 LCB or LCC, depending on the Ps and temperature range, Ps to 100 bar, Pe max 80 bar, higher pressures on request, Pa max 43 (74) bar, design temperature -10 ° C (-20 ° C) / + 60 ° C, Operating EN334 -10 (-20) ° C / + 60 ° C, lacquering Color: RAL9006, flange galvanized, internal Piping I / O 10L, pulse and respiration terminals 12L KG 14598, length 508mm, weight incl. Pilot system 290kg 305 / A + AR100 CS10 (-46 ° C) Pzul to 100 bar, Designtemp. -46 ° C, actuator housing Al (EN AW-6012 anodized), connectors 12L and G ¼ "reactor with int. Fine filter, regulator int. Attenuation and equalization system, Wh 20-60 bar,
AREFLUX 819 ANSI600 DN 150 7009642
Gas pressure regulator with power, self-operated, fail to close, ANSI 600 RF, CE tested to PED 97/23 / EC Module B and EN334, actuator housing ASTM A352 LCB or LCC, Ps to 100 bar depending on the material and temperature range, Actuator sleeve valve Ps 100 bar, Pa max 65 bar, Design temperature -10 ° C / + 60 ° C operating temperature EN334 - 10 (-20) ° C / + 60 ° C, paint color: RAL 9006, galvanized flange, internal piping E / O 10L, pulse and respiration terminals 12L KG 17471, Length 508mm, weight incl. Pilot system 360kg Pilot system 204 / A + R14 / A reflux 7,050,902 Pzul to 100 bar, EO terminals 10L and G ¼ ", with self-adjusting auxiliary pressure stage, with integrated filter, bar, case galvanized guide area 0.7 -43 and painted,
(Compensating diaphragm)
(Working diaphragm)
gas pressure regulator
DIVAL507/G 180BP-10 / FM7064001G
DN 25 Gas Pressure Regulator, spring-loaded, fail to open, CE approved PED 97/23 / EC module B and EN334, actuator housing EN-GJS400-15, threaded connection G1 "x G1", with integrated SBV port I / O10L (12L) (optional deactivated), with internal pulse line, Pu max 10 bar, Wh: 20 to 110 mbar, Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, 100 mm length without flanges, Pd adjusted to 30 mbar, integrated SBV adjusted to 45 mbar
Gas-Druckregelgerät DN 25
DIVAL507/G 180TR /DN 25 /X0150730
(Gas pressure regulator, PN20, spring-loaded, fail to open, CE tested according to PED 97/23 / EC and EN334, actuator housing EN-GJS400-15, threaded connection G1 "x G1" (optional Flange), with integrated connecting SBV 12L (optional deactivated - additional charge), with internal pulse line, Pumax 20 bar, outlet pressure range: 300-3000 mbar, Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, 100 mm length)
Gas Pressure Regulator
Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe 20 bar, Pa: 0.28 to 4.2 bar, design temperature -20 ° C / + 60 ° C, operating EN334 -10 (-20) ° C / + 60 ° C, Paint actuator housing color: RAL9006, Pulse connection 12L, breathing connection G½ "
DIVAL600/G 280TR PN16/25 DN 50
Spec. No. 7066008G Gas Pressure Regulator, PN 16/25, spring-loaded, CE approved PED 97/23 / EC module B and EN334, actuator housing GGG40, actuator 280mm, Ps 20 bar according to EN12186, Pe 20 bar, outlet pressure range: 0.28 to 4.2 bar (For Please order constant adjustment specify, otherwise Machining possible !!!) Design temperature -20 ° C / + 60 ° C, operating EN334 - 10 (-20) ° C / + 60 ° C, painting actuator housing hue: RAL9006, pulse terminal 12L, breathing connection G½ " Length 254 mm
regulator
regulator piloted
Two stage pressure regulator for domestic supply, integrated relief valve, over pressure safety shut off valve, under pressure safety shut off valve, Ps 8 bar, Pmax 8 bar, regulation pressure range Pa 13 to 350 mbar, over pressure shut off range Pso 32 to 450 mbar, under pressure shut off range Psu 6 to 200 mbar, relief valve range Ps 10 to 70 mbar, Qn 75 m³/h N.G. at Pe =<0,5 bar, ambient temperatur -20°C / +50°C, design temperatur -20°C / +50°C (other temperatures on request),
(Two-stage gas pressure regulator, Ps 8 bar, Pumax: 8 bar, mbar with integrated SBV, output pressure range 13-180 (Via different springs), with integrated safety shut- mbar 300 - with upper cut-off Who 35 gas shortage safety, internal thread connection G 1/2 "x G 3/4 "(other connections on request), Qn 25 m³ / h of natural gas at Pu 0.4 bar, ambient temperature -20 ° C / + 60 ° C, (Low temperature version on request) in line version, connection female thread in body, inlet G- "outlet G1", weight approx 1.4 kg Pds 21 mbar)
pump
Multiphase Flow Meter
filter
filter
filter
