| BRAND | Stahl |
| Product | 277858 / 8581/31-507 |
| Description | wall socket |
| Internal code | ONR4807293 |
| Custom code | 85366990 |
| Technical specification | 125 A wall socket explosion-proof 8581/31-507 Rated operating voltage: 277/480... 288/500 V AC Frequency range: 50/60 Hz Detailed number of poles: 3 P + N + PE Code color: black Coding (time setting): 7 Housing material: polyester, glass fiber reinforced Silicone-free: No Range of application (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6... T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T65 °C... T85°C Db Min. ambient temperature: -45 °C Max. ambient temperature: +40 °C Rated operation current: 125 A Min.2 ambient temperature: -45 °C Maximum ambient temperature.2: +60 °C Rated operating current2:100 A Ambient temperature min. F: -49 °F Ambient temperature max F: +104 °F Ambient temperature min. °F 2: -49 °F Ambient temperature max. °F 2: +140 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP66 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Introduction 1: M63 x 1.5 Introduction 1 Type: Polyamide cable connector Introduction 1 type: 8161/7-M63-4828-LT Introduction of 1 clamp.: 28 - 48 mm Introduction 2: M63 x 1.5 Introduction 2 Type: Polyamide sealing plug Introduction 2 type: 8290/3-M63 For more information, see: r-stahl.com Webcode: 8581A Substitute for material: 206786 |
Discover the superior quality and performance of the Stahl 277858 / 8581/31-507 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 277858 / 8581/31-507 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 277858 / 8581/31-507 :
At Onrion LLC , we offer the 277858 / 8581/31-507 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 277858 / 8581/31-507 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Increased Safety Exe Dual Certified ATEX / IECEx. SIZE: 360mm x 360mm x 91mm. MAX QTY OF ENTRIES PER FACE: 1xM20x1.5 & 1xM32x1.5. Tapped Entries. Terminal Type: WDU2.5, Terminal Quantity: 82, and Terminal Type: WDU4, Terminal Quantity: 12. Required Quantity: 12pcs. Arrangement: 08816E00 Stopper Plug
8146/1S71-3D-1TS35+32U- N 32 terminal
Box EEx e, T5, C side M20x1.5 6 pcs. / D M25h1,5 1pc. M20x1.5 2 pcs.
8146/2073 terminal box Ex i MaterialNr.: 8146259110
Control stationType : 8146/5061Technical data:Gas - Explosion protection: Ex II 2 G Ex de IIC T6 GbDust - Explosion protection: Ex II 2 D Ex tb IIIC T80°C Db IP66Certificate ATEX: PTB 01 ATEX 1024Certificate IECEx: IECEx PTB 06.0090Material: Polyester resinDimension: 170 x 227 x 91 mmDegree of protection: IP 66Ambient temperature: -20° C ... +40° CRated voltage: 230 V / 50 HzRated current: 6 AControl voltage: V / HzWiring diagram: Without wiringAlso certified to: on request1 pc(s) rotary actuator bk 64mm not lockableLabel 8602 ø51, engravablelabelling: OFF-Auto-Handcontrol switch 4-pole switch. options 1171 pc(s) bezel 72x72 for measuring instrumentdirekt meas. ammeter 72 x 72 mm 4-20/40mA0-20A1 pc(s) earth terminal USLKG 5
-special switch Ex II 2G Ex de IIC T6 containing : -1 8544/1-31 switch 3 pole 690V, 63A -1 black turn knob, 0/OFF – I/ON -1 external earth 10qmm -1 internal earth rail -2 M32 cable connectors type 32A2F
Distribution fuse
disconnect
Cable gland M20x1.5 Eexe
CABLE
8415/24-A-9 (OBSOLETE REPLACED BY 8013/321-AL)
INDICATOR-AMBER/24V DC
8415/24-G-9 (OBSOLETE REPLACED BY 8013/321-AL)
INDICATOR- GREEN/24V DC
8415/24-R-9 (OBSOLETE REPLACED BY 8013/321-AL)
INDICATOR- RED/24V DC
8415/24-W-9 (OBSOLETE REPLACED BY 8013/321-AL)
INDICATOR-WHITE/24V DC
Audible signalling device
P/N: 145317, Type: 8493/11-21-6
signaling device
SAFETY SWITCH/ 25 A, 3-POLE
P/N: 149135, Type: 8560/51-4061
small safety element
P/N:149164, Type: 8560/51-4222
Small fuse element
P/N: 150598, Type: 8570/11-304
Switch socket
Switch socket
Switch socket
(Switch socket explosion proof)
P/N: 150494, Type: 8570/11-506
Switch socket
3X16 A EX PROOF PLUG
plug
Plug explosion-proof
(Plug explosion Proof Type: 8570 / 12-406 Bemessungsbetr.spg. / Frequency: 380-415 V 50/60 Hz Operating current: 16 A Detailed Contacts 4 P (3 P + PE) Color code: red Coding (time position): 6 Housing material: Polyamide Field of Application (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex de IIC T6 Dust explosion protection: II 2 D IP66 80 ° C Ambient temperature min. : -30 ° C Ambient temperature max. +55 ° C Protection (IP): IP66 Terminals: 1.5 mm Cable entry: 8 ... 20 mm plug explosion proof)
P/N: 150854, Type: 8571/11-506
switch socket
PLUG,UTILITY, 2-POLES
