BRAND | Huba Control |
Product | 402.9110021 |
Description | Relative and differential pressure transmitter |
Internal code | ONR4730913 |
Technical specification | Pressure range Relative and differential 0 ... 3 – 50 mbar Operating conditions Medium Air and neutral gases Temperature Medium / ambient 0 ... +70 ºC Storage -30 ... +70 ºC Tolerable overload 100 mbar Rupture pressure at room temperature 200 mbar at 70 ºC 150 mbar Materials in contact with the medium Case construction Polycarbonate (PC) / Polyamide (PA) Diaphragm Silicone Sensor Ceramic Al2O3 (96%) Electrical overview Output 0.5 ... 4.5 V Power supply 10.2 ... 33.0 VDC Load > 15 kOhm (to GND) Current consumption < 8 mA Polarity reversal protection Connector and pcb version mechanically protected Electromagnetic compatibility The product is designed exclusively for installation in equipment. The customer is responsible for CE conformity. Dynamic response Response time < 10 ms Load cycle < 10 Hz Protection standard IP 00 Electrical connections Solderable pin in circuit board 3 pole onnector RAST 2.5 Adapter plate Mounted and soldered Pressure connection Pipe Ø 6.2 mm Mounting instruction Installation arrangement Diaphragm vertical Presssure connections facing downward Diapgragm horizontal Pressure connection P1 upwards Mounting Snap fitting 1) Adapter Mounting bracket |
Discover the superior quality and performance of the Huba Control 402.9110021 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 402.9110021 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 402.9110021 :
At Onrion LLC , we offer the 402.9110021 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 402.9110021 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Huba Control products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
