BRAND | Scherzinger |
Product | 4030-280-ZK-71-140 |
Description | Magnetic coupled External Gear Pump |
Internal code | ONR4661995 |
Technical specification | Fluid Designation: unknown Nominal Operating Temperature: 20±5 °C Technical data Explosion protection: 2014/34/EU - II 2G Ex h IIC Gb X // II 2D Ex h IIC Db X Main Sense of Rotation: left (ccw), View on Pump Shaft Displacement: 2,8 cc/rev. Port size: DIN ISO 228, G 1/2" Allowed pump inlet pressure: -0,9 ... 88 bar Operating temperature range: -20 to 130 °C Design Materials Body Material: SS 316L Gear Material: PEEK mod. Shafts: SS316TI Sleeve Bushings: PEEK mod. stat. Seals: PTFE Shaft Sealing: Magnetic Coupling, max.2 Nm Magnets Sm2Co17, encapsulated in SS 316L to be assembled to a motor with motor side mag. coupling hub Motor standard: IEC 72-1 Motor size: IEC71 Motor design: IMB34 Adapter diameter: 140 mm Shaft: 14x30 mm recc. power: 0,12 kW recc. speed: 750 RPM Important indications Please install a screen with 50 µm mesh size at inlet side Pump not suitable for fluids with magnetic/iron particles Pump not usable for fluids with particle contamination Cleanliness level of fluid acc. ISO 4406 should be better than 19/17/14 |
Discover the superior quality and performance of the Scherzinger 4030-280-ZK-71-140 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4030-280-ZK-71-140 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4030-280-ZK-71-140 :
At Onrion LLC , we offer the 4030-280-ZK-71-140 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 4030-280-ZK-71-140 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
