| BRAND | Wika |
| Product | 432.50 |
| Internal code | ONR4845209 |
| Technical specification | Diaphragm pressure gauge, overload safety Series EN 837-3 Model: 432.50 Specifications according to data sheet: PM 04.03 Case filling: Silicone oil Case Material: Stainless steel 1.4301 (304) Case: Safety level “S1” per EN 837-1: With blow-out device Nominal size: 160 mm Measuring range: Gauge pressure range Scale range:0...160 mbar Process connection: ASME B1.20.1 , ½ NPT Connector location: lower mount Window: laminated safety glass (Shatter Proof) Pointer: adjustable pointer Accuracy: Class 1.6 Diaphragm element Material : Stainless steel Lower Body Material: Stainless-Steel Pointer: adjustable pointer Ingress protection: IP 65 Permissible medium temperature: +200 °C Permissible ambient temperature: -40 … +60 °C Pressure Gauge Standard: International (standard Europe) |
Discover the superior quality and performance of the Wika 432.50 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 432.50 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 432.50 :
At Onrion LLC , we offer the 432.50 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 432.50 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
PCS2MB: MAX .PRESSURE:10 BAR, PROOF PRESSURE:40 BAR
0.8 to 6 Bar
PCS2MB: PRESSURE:10 BAR, PROOF PRESSURE:40 BAR
1.6 to 10 Bar
1400s937 03 2014 prüf nummer 14 101 pressure gauge with alarm contacts typ 212.20.100 kont 821.1 0-10bar umax 250vac pmax 30w 50va KI 1.0
Switch gauge with alarm contact
PGS23.160 821.3 PMAX : 20 W , 20 VA , UMAX : 250 V , IMIN : 20 MA FLANGE : PM2 , 150 LB , B16.3 A/
Switch gauge with alarm contact
PRESSURE GAUGE FOR GAS 3500 - 4000 PSI, DIAMETER 2 INCH
Pressure gauge for gas 3500 - 4000 PSI, diameter 2 inch, connect with air at the bottom, having liquid inside, tube diameter 1/4 npt, graduation 100 psi
PRESSURE GAUGE FOR GAS 3500-4000 PSI, DIAMETER 2 AND 1/2 INCH
Pressure gauge for gas 3500 - 4000 PSI, diameter 2 and 1/2 inch (63.5 mm), connect with air at the back, having liquid inside, tube diameter 1/4 npt, graduation 100-200 psi
PRESSURE GAUGE WITH LIQUID FILLING , 0-1000 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-1000 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING , 0-1200 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-1200 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING , 0-30 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 100 mm WITH LIQUID FILLING , 0-30 BAR
PRESSURE GAUGE WITH LIQUID FILLING , 0-500 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-500 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING, 0-100 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING, 0-100 BAR
PRESSURE GAUGE WITH LIQUID FILLING, 0-1000 M BAR MODEL; 233.50
Lower back mount LBM, surface mounting flange , No minal size OD 100 mm WITH LIQUID FILLING, 0-1000 M
PRESSURE GAUGE WITH LIQUID FILLING, 0-16 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 100 mm WITH LIQUID FILLING, 0-16 BAR
PRESSURE LOWER MOUNT LM,SURFA MOUNTING FLANGE ,NOMINAL SIZE OD 160 MM WITH LIQUID FILLING, 0-30 BAR
GAUGE WITH LIQUID FILLING, 0-30 BAR
Göstergeli elektronik basınç ölçer 1 M two switching outputs, (PNP) only with M12x1 plug, 4-pin N 2 B 3 C4 4 GD G 1/2 B NC 5 M4 4-pin locking plug M12x1 IP 67 NC 6 Z Without NC 7 Z Without NC
LENGHT 150MM, THICKNESS 3MM, COMPLETE WITH TERMINAL HEAD
R5502 -1-C1E-BK-E160GZ-ZZZ DIAL-T-1AZ1ZZZZZ
Bimetallic thermometer, chemical version Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: R 5502, initial size 100, of connection radial Design of connection: 1 Plain stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: plain, without thread Stem diameter: 10 mm Installation length L1: 160 mm Window: Instrument glass Connection position: bottom (radial) Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1
RANGE: -1BAR ~ 1.5 BAR O/P SIGNAL: 4-2MA/O-10VDC MODEL: S-10
VACUUM TRANSMITTER
(Druckmesserumformer for general applications)
