BRAND | Scherzinger |
Product | 451 FAR/DU |
Description | Gear flange pump |
Internal code | ONR4536757 |
Custom code | 84136039 |
Technical specification | 201430 • Pump not suitable for particle-laden media • According to ISO 4406, the purity class should be at least 19/17/14 • Please install a coarse filter with a mesh size of 50µm in front of the pump specifications Direction of rotation: right (cw), look at the pump shaft Displacement volume: 31 cm³/rpm Connections: DIN ISO 228, G 1" Perm. Inlet pressure: -0.7... 0.5 bar Perm. Differential pressure: 30 bar (viscosity-dependent) Operating temperature range: -20... 80°C construction materials Housing material: EN GJL 250 Gear material: EN 11SMn30 Shaft material: EN 11SMn30 Plain bearing material: EN GJL 250 stat. Seal material: NBR Shaft seal: Rotary shaft seal, NBR flanged pump with centering ring and 4 screw holes with free shaft end Painting: RAL 7035, light grey (primer) |
Discover the superior quality and performance of the Scherzinger 451 FAR/DU with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 451 FAR/DU is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 451 FAR/DU :
At Onrion LLC , we offer the 451 FAR/DU at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 451 FAR/DU ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
SCREW BOLT
SEALING NUT
SEAL
CASING
CASING
BUSHING
SCREW
SCREW
SCREW
SEAL
SUPPORT RING
SPRING
CUP SPRING
ROTARY SHAFT SEAL
O-RING
O-RING
O-RING
PIN
Needle bearing
Needle bearing
Ball Bearing
