BRAND | Voith |
Product | 487TVG |
Description | Turbo clutch |
Internal code | ONR4488558 |
Custom code | 84836080 |
Technical specification | Consists of: -Voith fluid coupling 487 TVG Motor: E-motor Motor type: asynchronous motor Engine power P1 [kW]: 160 Engine speed n1 [rpm]: 1480 Work machine type: Unknown Rated power P2 [kW]: unknown Filling [l]: 17 Slippage approx. [%]: 4.5 Fuse screw cap. [ºC] 160 X1 Eye screw: Yes Replacement for VTK number: 7589286 Installation position: horizontal Drive via: outer wheel Execution: Dimensions: according to Installation plan: 3600-044602 Material runner parts: silumin Drive side: Elast. Connection coupling type EPK Bore diameter: 80.00 Holefit: H7 Feather key: DIN 6885/1 output side: Connection via: clutch hub Bore diameter: 55.00 Hole fit: G6 Shafts/spigot length: 140,000 Feather key: DIN 6885/1 Bore depth: 155.00 - 1x sealing elements VITON -preservation indoor and outdoor - up to 12 months - 1 x connection coupling EPK (ring aluminium), drilled |
Discover the superior quality and performance of the Voith 487TVG with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 487TVG is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 487TVG :
At Onrion LLC , we offer the 487TVG at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 487TVG ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Voith products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
