Buy 764020.0500 from Luetze in United States

BRAND	Luetze
Product	764020.0500
Description	LCIS Solid State Relay
Internal code	ONR3813481
Weight	0.03
Technical specification	Rated voltage UNDC 24 V Input voltage rangeDC 16.8 V – 30 V Rated current INDC 9 mA Protection device Input Varistor Reverse diode Status display inputLED green Activation voltage>16.8 V Interrupting voltage<10 V Switching element MosFet N/O contact Min. switching voltageAC/DC 2 V Max. switching voltageAC/DC 253 V Min. switching currentAC/DC 1 mA Max. switching currentAC/DC 2 A @ 100 % ED Derating dependence of assembly installed with ≥20 mm: no derating installed without distance: ≤60 °C: max DC 2 A >60 °C: -25 mA/°C Inrush current10 A/20 ms @ 1 Hz Leak currentAC: <0.2 mA, DC: <1µA Switch-on delay<150 µs @ Imax Shutdown delay<100 µs @ Imax Protection deviceVaristor Short circuitnon short-circuit proof Switching frequency500 Hz General Housing materialPA 6.6 (UL 94 V-0) Color of the housing RAL 7012 basalt grey Protection classIP20 Mounting DIN rail mountable TS35 (EN 60715) Installation positionany Insulation voltage input / output4.0 kVeff Safe isolationyes Clearance/creepage dist. (control/load side)>5.5 mm Operation temperature range-25 °C … +60 °C Storage temperature range-40°C…80°C Dimensions (w × h × d)6,2×93×73 mm Connection type Push-In single wire 0.25 mm2–2.5 mm2 / AWG 20–14 fine stranded wire with ferrule 0.25 mm2–1.5 mm2 / AWG 20–16 StandardsEN 60947-5-1 Approvals cULus in preparation DNV GL in preparation

Discover the superior quality and performance of the Luetze 764020.0500 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The 764020.0500 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of 764020.0500 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the 764020.0500 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the 764020.0500 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Luetze products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
