| BRAND | Stahl |
| Product | P/N: 213477, Type: 8146/5-V37-310-51-1010-K |
| Description | Safety switch 180 A |
| Internal code | ONR3811816 |
| Weight | 14.36 |
| Custom code | 85371098 |
| Technical specification | Explosion-protected Spare of type : 8537/2-308-5001-K AC rated operational voltage : 400 V Rated operational current : 180 A Enclosure material : Polyester resin Glass fibre reinforced Detailed number of poles : 3-pole Auxiliary contact NC : 1 NC Auxiliary contact NO : 1 NO / delayed Additional terminal : Standard (without) Application range (zones) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex db eb IIC T4 Gb Dust explosion protection : II 2 D Ex tb IIIC T130 °C Db Special conditions for extended ambient temperature, see operating instructions: Min. extended ambient temp. : -40 °C Max. extended ambient temp. : +50 °C Degree of protection (IP) : IP66 Cable entry : 2 x M63 Ø 28 ... 48 mm 1 x M20 Ø 4 ... 13 mm Connection cross-section : 95 ... 120 mm Aux. cont. conn. cross-section: 0,75 ... 2,5 mm2 Finely stranded |
Discover the superior quality and performance of the Stahl P/N: 213477, Type: 8146/5-V37-310-51-1010-K with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N: 213477, Type: 8146/5-V37-310-51-1010-K is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N: 213477, Type: 8146/5-V37-310-51-1010-K :
At Onrion LLC , we offer the P/N: 213477, Type: 8146/5-V37-310-51-1010-K at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the P/N: 213477, Type: 8146/5-V37-310-51-1010-K ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
