| BRAND | Buschjost |
| Product | 8318555.0000.00000 |
| Description | hydraulic valve |
| Internal code | ONR4360494 |
| Custom code | 84812010 |
| Technical specification | 83160 series Designation 4/2-way valve block, NG 16 Type slide valve Control hydraulic Connection G 1/2 Plate structure Pressure range max.operating pressure 315 bar Press pressure set to 200 bar, switching pressure set to 150 bar Differential cut-off: 100 bar Medium mineral oil according to DIN 51524/51525 Viscosity 10-500 qmm / S Temp. Medium -20 to + 80 ° C Ambient temp. -20 ° C to + 50 ° C Any installation method Housing made of gray cast iron Material seal NBR mech. Measuring connection M-P, G 1/4 Additional information about pump flow rate 10 - 70 l / min, Mass: 7.8 kg This product contains wear parts which depends on the use, subject to wear and tear |
Discover the superior quality and performance of the Buschjost 8318555.0000.00000 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 8318555.0000.00000 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 8318555.0000.00000 :
At Onrion LLC , we offer the 8318555.0000.00000 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 8318555.0000.00000 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Buschjost products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
elektrovalf
Water Solenoid Vale complete with body and diaphragm
2/2-way solenoid valve
8212600.8001 - NOT AVAILABLE, ALTERNATIVE 821600.8001.23050
16VA 05-10 Valve inlet and outlet diameter of 1.5 finger band.
2/2-way solenoid valve
8234300 : 8304230 VOLT 40 - 60 HZ25 VA 0 - 16 BAR1300- OBSOLETE, REPLACED BY 8254300.9304.23049
valve
230v 50-60hz 18va
Customs tariff 84818079 0.495 kg series 82400 Mark 2/2-way solenoid valve Type diaphragm valve Control controlled indirectly Connection G 1/2 Nominal diameter 12 mm Pressure range from 0.1 to 16 bar elektr.Ausst. Connector Form A kv-value 3.80 m³ / h Temp.Medium 90 ° C Temp.Umgebung 50 ° C voltage 24V frequency 50Hz Protection type IP 65 Aufn.Anzug 15 VA Aufn.Betrieb 7 W Einsch.Dauer 100%
Magnetventil
solenoid valve(230V 50-60Hz 7W PA:0,1-12 bar 4213)
valve
2/2-Wege Magnetventil
Bobini: Parts No: 8240401.9101 205 volts AC 8 Watt ED 100%
(2/2-way solenoid valve)
(2/2-way solenoid valve)
valve Body
82 540 2/2 way
(Tariff 84818079 1.045 kg net price series 82540 Mark 2/2-way solenoid valve Type diaphragm valve Control force pilot, G 3/4 Nominal diameter 20 mm Pressure range 0-16 bar elektr.Ausst. Connector Form A built-in rectifier kv-value 5.80 m³ / h Temp.Medium -10 to + 90 ° C Temp.Umgebung -10 to + 50 ° C voltage 230V frequency 40-60Hz Protection type IP 65 Aufn.Anzug 20 VA Aufn.Betrieb 20 VA Einsch.Dauer 100%)
(Mark 2/2-way solenoid valveType diaphragm valveControl force pilotConnection G 1 1/4Nominal diameter 32 mmPressure range 0-16 barkv-value 23 m³ / hTemp.Medium -10 to + 80 ° CTemp.Umgebung -10 to + 40 ° Cvoltage 230Vfrequency 40-60HzProtection type EEx me II T3, IP 65Ex II 2 GD T 140 ° Celektr.Anschl connection housing for cable 5-10 mmCable entry M16 x 1.5Aufn.Betrieb 195 mAEinsch.Dauer 100%Installation method required, preferably with solenoidvertically upwardsWst.Gehäuse steelWst.Dichtung NBR-K)
2/2-way solenoid valve
2/2-way solenoid valve
110V ac, 10 HAMPERS Reperaturkit (diaphragm + bow) with nominal diameter DN40
