BRAND | Indexator |
Product | 8400009 / XR400 I |
Internal code | ONR4458731 |
Custom code | 84122981 |
Technical specification | INDEXATOR Rotator XR 400-I ⦁ Compact rotator with large slewing ring bearing ⦁ External force transfer via the robust housing ⦁ Inwardly floating vane motor, This makes it particularly durable ⦁ Suitable for oscillating suspension and fixed mounting on the excavator ⦁ Top mount suitable for Indexator headstock with 80 mm bolt and 275 mm pendulum width (item no. 8000775) ⦁ For extreme applications with particularly high requisitions ⦁ Extremely high torques ⦁ Suitable for reciprocating material handling machines Suspension 25 - 45 t net weight, excavator with Two-shell gripper up to 2.5 m³ and multi-shell gripper up to 1.2 m³.55,000 kg max. static load, 20,000 kg max. dynamic load, 14,000 kg max radial load ⦁ Torque of 4,100 Nm at 250 bar ⦁ Oil requirement 35 l/min ⦁ Weight 180 kg ⦁ Top mount: flange with blind holes and Thread (bolt circle 12xM20-240 mm) ⦁ Bottom mount: 450 mm diameter bolt circle (30x14-450mm) ⦁ Top hydraulic connections 2 x G 1" + 2 x G 1/2" ⦁ Bottom hydraulic connections 2 x G 1" Areas of application: ⦁ Use on reciprocating material handling machines Suspension 30 - 50 t operating weight ⦁ Excavator with two-shell gripper up to 2.5 m³ ⦁ Excavator with multi-shell gripper up to 1.2 m³ ⦁ Excavator with wood, multifunctional or sorting grabber in Fixed installation up to 27 t operating weight |
Discover the superior quality and performance of the Indexator 8400009 / XR400 I with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 8400009 / XR400 I is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 8400009 / XR400 I :
At Onrion LLC , we offer the 8400009 / XR400 I at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 8400009 / XR400 I ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Indexator products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
