BRAND | Stahl |
Product | 277863 / 8581/12-507 |
Description | Cable plug |
Internal code | ONR4807261 |
Custom code | 85366990 |
Technical specification | plug 125 A; - explosion-proof 8581/12-507 Rated operating voltage: 277/480... 288/500 V AC Frequency range: 50/60 Hz Detailed number of poles: 3 P + N + PE Code color: black Coding (time setting): 7 Case material: polyamide Silicone-free: No Range of application (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6... T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T65 °C... T85°C Db Min. ambient temperature: -45 °C Max. ambient temperature: +40 °C Rated operation current: 125 A Min.2 ambient temperature: -45 °C Maximum ambient temperature.2: +60 °C Rated operating current2:100 A Ambient temperature min. F: -49 °F Ambient temperature max F: +104 °F Ambient temperature min. °F 2: -49 °F Ambient temperature max. °F 2: +140 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP66 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Cable diameter: 30.00 - 45.00 mm For more information, see: r-stahl.com Webcode: 8581E Substitute for material: 153476 |
Discover the superior quality and performance of the Stahl 277863 / 8581/12-507 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 277863 / 8581/12-507 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 277863 / 8581/12-507 :
At Onrion LLC , we offer the 277863 / 8581/12-507 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 277863 / 8581/12-507 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
