Buy 97/DF500-Z2 from Schniewindt in United States

BRAND	Schniewindt
Product	97/DF500-Z2
Internal code	ONR519980
Weight	1
Technical specification	Type 97/DF500-Z2 Drawing No. 2.01.277.0.0 Electrical data Total power (kW) 500 Tolerance of power (%) +5/ -10 Supply voltage (V) 400 Connection Delta Protection mode IP 54 Operationg Conditions Medium Thermal Oil Flow rate 72000 Unit kg/h Inlet temperature (°C) 220 Outlet temperature (°C) 231 zul. min Temp. TS (°C) 0 zul. max Temp. TS (°C) 300 Operating pressure (bar g) 5 maximum permissible pressure PS (bar g 6 Test pressure 9 Mounting position horizontal Design Code/Acceptance DGRL Kat. IV / TÜV Nord Design code / Approval: AD2000 in addition: Design calc. acc. ASME VIII Div.1 (but materials + manufacturing acc. AD2000) mechanical design Heating element Tubular heating elements Diameter (mm) 11,5 Material of heating element 1.4571 Surface load (W/cm²) 3,2 Quantity of heating elements 90 Heating elements eingeschweißt Immersion length of heating elements 2.650 unheated length (mm) 250 . 4 pcs. Dual-Thermocouples, 2 x NiCr-Ni, Type "K" . (2 pcs. in each immersion heater) . (for connection to intrinsic safe circuit Ex ic) Durchmesser Umlenkblech 198 Sealing GISO Nominal size / Nominal diameter (DN) 8" Pressure stage (bar) 300 lbs Material P250GH (1.0460) Type of spacers Distanzscheibe Rautenform Number of Spacers 12 Connection box 500 x 500 x 210, 1.4301 Quantity of cable glands 8 Cable gland 6 x M63x1,5, 2 x M16x1,5 Sealing graphite on stainless steel insert Heating Vessel Material of vessel carbon steel,coated temperature resistent Inspections / Tests . ---------------------- . 1) The heater needs to be operated with a suitable . electric control unit only. Temperature controll, . temperature limitation and flow monitoring need . to be implemented propperly. . 2) The thermocouples are for temperature limi- . tation purpose. They need to get connected . through intrinsic safe circuits (Ex ic) to . electronic safety temperature limites (ESTBs) . inside of the electronic control unit. . The trip points of this ESTBs need to be adjusted . to a maximum temperature of 300°C and locked. . The control unit needs to initiate an automatic . power shutdown in case of ESTB tripped. . 3) The equippment is marked as T. to indicate that . additional measures are necessary in order to . certify for a temperatur class. In this case, the . temperature limitation need to get implemented . propperly by the electric control unit and a . thermal piece test needs to get performed . under operation conditions. . 4) Thermal piece test is not included in the . price. We can offer it separately if reed.

Discover the superior quality and performance of the Schniewindt 97/DF500-Z2 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The 97/DF500-Z2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of 97/DF500-Z2 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the 97/DF500-Z2 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the 97/DF500-Z2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Schniewindt products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
