BRAND | GSR |
Product | G040.002601.069.099.069 |
Internal code | ONR4837682 |
Custom code | 84818079 |
Technical specification | for connection to 48V 50-60HZ Reference D40251001.032HA consists of: 040.002601 2/2-way valve Type: D4025/1001/.032-HA Control type: servo-controlled Construction: diaphragm valve Function: NC - closed without power Connection: G1" socket, DIN ISO 228/1, seat diameter 25.0 mm Pressure range: 0.3-20 bar, delta-p min. 0.3 bar Medium temperature: -10°C/+80°C Ambient temperature: -10°C/+35°C Viscosity: 22 mm²/s Valve housing: brass 2.0402 Internal parts: brass 2.0401/stainless steel 1.4104 Seal: NBR Installation position: any position, preferably with a stationary magnet Note: HA = valve with emergency manual operation B0051.000149 with magnetic coil Type: .032 Voltage: 48V 50-60HZ Power: 20/17VA Protection class: IP65 Turn-on time: 100% ED |
Please Contact Us to Order to offer competitive prices and delivery time for GSR - G040.002601.069.099.069 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
