BRAND | GSR |
Product | P/N: 063.000789, Type: 2813E000 |
Description | solenoid valve |
Internal code | ONR4439187 |
Custom code | 84812090 |
Technical specification | 2/2 way solenoid valve Type: 2/813-24-0804-7555-AS Control type: pressure controlled, differential pressure min.0 bar Construction: disc seal Function: NC - closed without pressure with spring force against the medium flow Connection: weld ends DN20 Seat: 20mm Pressure range: 0 - 9 bar Medium temperature ፦40°C/+200°C outdoor temperature ፦40°C/+60°C viscosity: 600 mm²/sec Valve body: stainless steel 1.4408 Inner parts: stainless steel 1.4301/stainless steel 316Ti Sealing: PTFE Drive housing: brass-electroplated nickel plated Drive seal: FKM Installation position: drive in upright or horizontal position Pilot valve connection: G1/8 Control pressure: 4-10 bar. Neutral, gaseous media. .: For the maximum operating pressure specified above .: is a control pressure of at least 6 bar required. Option: AS = valve with weld ends Remark: valve plate attached by nut |
Please Contact Us to Order to offer competitive prices and delivery time for GSR - P/N: 063.000789, Type: 2813E000 solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
