BRAND | Bauer |
Product | BF10-04/DPE08XB4-TOF-S/ES010A9HN |
Internal code | ONR4960070 |
Custom code | 85015100 |
Technical specification | Material number 30720592 BCAS part number 189J4101 Description BF10-04/DPE08XB4-TOF-S/ES010A9HN Flat gear motor with single-disc spring-brake BF10-04/DPE08XB4-TOF-S/ES010A9HN Motor power: 0.75 kW AW speed: 36.0 r/min Lineup: H4 Terminal box location: II/C Corrosion protection: standard Painting: RAL 7031 Dimension diagram: BF10-BF10Z Catalogue: B 2010 Suitable for operation with static inverters in the frequency range: 5 - 50 Hz Voltage: 76 - 400 V Y Power: 0.047 - 0.445 kW synchronize. Speed: 3.7 - 37.5 r/min Konst. Load moment: 119 Nm Load current approx.: 1.56 A Operating factor: 2.0 Gearbox design: Type: BF10 2-stage flat transmission Design code 04 Goured with torque support Hollow shaft with spring groove (d: 25 mm) Total reduction i: 39.75 Oil variety/quantity (l): CLP 220/1.1 Additional/special versions: 2 rubber buffers are supplied loose. Engine design: Type: DPE08XB4-TOF-S three-phase cage rotor motor Design speed: 1425 r/min Voltage: 400 V Stator circuit: Y Frequency: 50 Hz Rated current: 1.86 A cos phi power factor: 0.71 Efficiency: IE3 - 82.5% (according to EN 60034-2-1) Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermostat “opener” for shutdown in accordance with insulation class F according to additional connection diagram ZK010.1030-13. Brake design: holding brake under the fan cover Type: Single disc spring brake ES 010 A 9 HN Setting value: 10.0 Nm IP protection class according to EN 60 529: IP 65 coil voltage: 180 V coil current: 0.17 A Additional dimension diagram: N-BR Cable design, connection ends of the magnetic coil routed to the rectifier in the motor terminal box. Additional/special versions: With non-lockable hand ventilation. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.12 A DC output: 180 V |
Discover the superior quality and performance of the Bauer BF10-04/DPE08XB4-TOF-S/ES010A9HN with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BF10-04/DPE08XB4-TOF-S/ES010A9HN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BF10-04/DPE08XB4-TOF-S/ES010A9HN :
At Onrion LLC , we offer the BF10-04/DPE08XB4-TOF-S/ES010A9HN at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BF10-04/DPE08XB4-TOF-S/ES010A9HN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
