| BRAND | ProMinent |
| Product | BT4B1604PPB3000U1010000 |
| Description | Magnetdosierpumpe beta 4b |
| Internal code | ONR3359200 |
| Weight | 5 |
| Custom code | 84135040 |
| Technical specification | BT4B Baureihe : BT4B - BETA 4 - Pumpe Version B Pumpentyp : 1604 - 16bar, 3,6l/h Ans.6x4/SS6x5 Dosierkopfwerkstoff : PP - Polypropylen Dichtungswerkstoff : B - Standard Membr. m.FPM-B Dicht. Dosierkopfausführung : 3 - m.Entlüftung , m.Ventilfeder Hydraulischer Anschluss : 0 - Standard-Anschluss Ausführung : 0 - Geh.RAL5003/Haube RAL2003 Logo : 0 - mit PM-Logo Spannungsausführung : U - Universal 100-240 V Kabel und Stecker : 1 - 2m offenes Ende Relaisfunktion : 0 - ohne Relais Zubehör : 1 - Dos.v.u.Fußv.,2mSchl.5mPE Schl Steuerungstyp : 0 - ohne Verriegelung Steuerungsvariante : 0 - Puls- Control Fernstop : 0 - Pause Öffner, Niv. Öffner Auxiliarfrequenz : 0 - extern Frequenz = 180max Zulassung : 01 - CE Frequenz (Hz) : 50/60Hz Spannung (V) : 100-230V Leistung (W) : 16,5W Schutzart : IP66/NEMA4X Förderleistung (l/h) : 3,6l/h Gegendruck (bar) : 16bar Statistische Warennr.: 84135040 Herkunftsland: DE Kein Dual-Use |
Discover the superior quality and performance of the ProMinent BT4B1604PPB3000U1010000 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BT4B1604PPB3000U1010000 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BT4B1604PPB3000U1010000 :
At Onrion LLC , we offer the BT4B1604PPB3000U1010000 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BT4B1604PPB3000U1010000 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ProMinent products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
