BRAND | Rembe |
Product | BT-KUB-16 |
Internal code | ONR4205205 |
Custom code | 73269098 |
Technical specification | Product no.: 20800204 Reversing Binding Rod Bursting Disc Medium in front of the bursting disc: gas Nominal diameter (DN): 400 mm Relief area: 1100 cm² Type of protection: overpressure Holder system: IG-KUB Burst pressure: 3.15 bar g Burst temperature: 22 °C Lower Burst Tolerance: 5% Upper Burst Tolerance: 5% Working pressure: 0.227 bar g Vacuum resistance: absolute max. working temperature: 153 °C Buckling rod: ss316 Sealing part: ss316 Certification: ASME Sec VIII Div. 1 Test Standard: ASME Sec VIII Div.1, Edition 2019 Customs tariff No: 73269098 Material Certificate Product no.: 164-1000000027 2 St according to EN 10204/ 3.1 one material certificate for each - Sealing part - Bucklink bursting element |
Discover the superior quality and performance of the Rembe BT-KUB-16 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BT-KUB-16 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BT-KUB-16 :
At Onrion LLC , we offer the BT-KUB-16 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BT-KUB-16 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rembe products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
