Buy CAF10-G56S4U / 2010000132 from HIMMEL in United States

BRAND	HIMMEL
Product	CAF10-G56S4U / 2010000132
Description	worm gear motor
Internal code	ONR4940028
Custom code	85015100
Technical specification	6-pin arting plug with mating plug Dimension sheet: CAF14/600036 Gearbox design/Type: HIMMEL® worm gear motor/HIMMEL® -worm gear motor Transmission Type/Type: CAF10-G56S4U Dimension sheet: CAF14/600036 Output speed/ Output speed [1/min; rpm]: 3.00//3.60 Translation/Ratio [i]: 463.65 Color/colour: RAL 9006 white aluminium/White aluminium Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP55 Design/mounting position: H-05-A Output torque/ Output torque [Nm]: 56//56 Direction of rotation: right/right [CW] Output shaft gearbox/ Output shaft [mm; inch]: H20x124.50 Gearbox bearing: assigned bearings Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.22 Flange diameter/Flange diameter [mm; inch]: A140 Shaft material/Shaft material: C45 Gearbox sealing/Sealing: shaft seal ring (WDR)/shaft seal ring Label/Approval\|Identification/Certification: CE Number of poles/poles: 4 Rated frequency/ Nominal frequency [Hz]: 50//60 Rated voltage/nominal voltage [V]: 220-240/380-420//254-277/440-480 Circuit/ Wiring: S100//S100 (D/Y//D/Y) Rated power/nominal power [kW]: 0.06//0.072 Rated motor speed/Motor speed nom. [1/min; rpm]: 1380//1680 Rated current/Nominal current In [A]: 0.42/0.24//0.43/0.25 CosPhi/CosPHI: 0.68 KK location/Terminal box position: 3D KK version/Terminal box type: plastic one-piece angled with harting plug/ plastic-monobloc-slope with Harting connector Winding protection/Motor protector: ohne/without Motor output shaft/Output shaft [mm; inch]: V11x24.5 Sealing motor/Sealing motor: normal/normal Insulation class: F Operating mode/Duty type: S1 Fan/Fan: without/non-ventilated

Discover the superior quality and performance of the HIMMEL CAF10-G56S4U / 2010000132 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The CAF10-G56S4U / 2010000132 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of CAF10-G56S4U / 2010000132 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the CAF10-G56S4U / 2010000132 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the CAF10-G56S4U / 2010000132 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply HIMMEL products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
