BRAND | Globtop |
Product | CFIB - 2 - MA - 35H - C - S |
Description | Housing |
Internal code | ONR4815479 |
Custom code | 90330000 |
Technical specification | CF series mod. CFIB in 316L stainless steel, with position indicator open/closed for rotary valves (maximum resistance to chemical and atmospheric agents). - Atex Exia certification (BVI 19ATEX0036X): Ex II 2GD Exia IIC T6, T5, T4 Gb Ex ia IIIC T85/T100/T135°C Db (Also from -50°C to +75/+90/+100°C) - Cable entry: n. 3 3/4 “npt-f holes - Terminal block: 6 terminals plus ground connection (option 12 terminals) - Degree of protection: IP66/67 - Treatment: electropolishing - Position indicator: three-dimensional dome color red-green - shaft coupling: namur - Each case is equipped with No. 2 GO SWITCH with the following characteristics: - Passive Hermetic Series 30 Mod. 35 magnetic stopper (without power supply and without Reed contacts) - mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; hermetic - contact range: 4A AC to 120V AC, 2A AC to 240V AC and 3A DC 24V DC resistive load (maximum values for power barrier selection: - Ui 30V, Ii 120mA, Pi 1000mW) - Sensitive distance: 3 mm. (with ferrous feedback) - differential (hysteresis): 3 mm. (with ferrous feedback) - response time: 8 milliseconds - working temperature: see T.amb. of case certification - shell: cupronickel - nr.4 PVC-insulated connection conductors 105°C |
Discover the superior quality and performance of the Globtop CFIB - 2 - MA - 35H - C - S with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CFIB - 2 - MA - 35H - C - S is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CFIB - 2 - MA - 35H - C - S :
At Onrion LLC , we offer the CFIB - 2 - MA - 35H - C - S at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CFIB - 2 - MA - 35H - C - S ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Globtop products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
