BRAND | TEKNIC |
Product | CPM-SDHP-N0563P-ELN |
Description | motor |
Internal code | ONR4468003 |
Technical specification | Motor Frame SizeNEMA 56 - 7.47 in (189.74 mm) sq. Length9.22 in (234.19 mm) Input Voltage Range Input Voltage for 5-wire systems100-240 VAC (1- or 3-phase) 300-415 VAC (3-phase, 5-wire) Peak Torque (@230 VAC 3-ph)4,652 oz-in (32.9 N-m) Cont. (RMS) Torque (@230 VAC 3-ph)1,147 oz-in (8.1 N-m) Max Speed (@230 VAC 3-ph)2760 RPM Achievable ResolutionEnhanced Option0.029 degrees Repeatability0.006 degrees Shaft Diameter0.625 in (15.88 mm) Weight25.0 lb (11.3 kg) Rotor Inertia103.4 oz-in² (18.9 kg-cm²) Logic Input Voltage Range4.0 to 28 VDC Maximum Radial Load170 lbf (756.2 N) Maximum Thrust Load40 lbf (177.9 N) in; 70 lbf (311.4 N) out Ambient Temperature1-40° to +70° C Ambient Humidity0-95%; non-condensing |
Discover the superior quality and performance of the TEKNIC CPM-SDHP-N0563P-ELN with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CPM-SDHP-N0563P-ELN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CPM-SDHP-N0563P-ELN :
At Onrion LLC , we offer the CPM-SDHP-N0563P-ELN at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CPM-SDHP-N0563P-ELN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply TEKNIC products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
