| BRAND | Demag |
| Product | DC-WindCC 10-350 1/1 H150 V24/6 690/50 |
| Description | DC wind chain hoist |
| Internal code | ONR4880050 |
| Technical specification | The chain hoist is mounted in the existing arm of the swing crane Existing slewing crane Order No. 387520 (2016) Factory No. 94712653 chain hoist The following equipment is included in the standard package: - Galvanically galvanized chain for use in maintenance - The brake-clutch system keeps the load safe in every operating situation and makes load bagging impossible. - The corrosion-protected brake with protection class IP 55 is also equipped with protection class IP 55 electric hood - no damage to the inner or outer surface of the tower when lifting due to a protective cuff on the hook harness - Contactor control with 48 V control voltage - An operating limit switch for the highest and lowest hook position, to safely switch off the chain hoist in the end positions - An operating hours meter that can be read from the outside - Two standard lift speeds as main and fine stroke - The speed-monitored brake and clutch principle ensures a high level of safety and a long service life - Transmission is maintenance-free for up to 10 years supply network Line voltage 690 V Control voltage 48 V Line frequency 50 Hz Network type three-phase three-phase Technical data chain hoist Load capacity 350 kg FEM/ISO Group 1Bm FEM chain 1cm 5 x 15 chain for use in maintenance mode Hakenweg 150 m Control cable length 1.5 m Compensation 1/1 Lifting speed approx. 24.0/6.0 m/min Hoist voltage 690 V/ 50 Hz ZNK 100 B 8/2 lift motor Duty time 40/20% Rated power 2.30/0.57 kW Protection class IP 55 Insulation class F ambient Planned deployment site Operation in the nacelle of a wind turbine Operating temperature - 30 °C to + 45 °C Survival temperature - 45°C to +50°C Maximum humidity 80% in the gondola Surface protection and coloring High-quality powder coating on the aluminum components of the chain hoist ensures very good protection against corrosion Hoist colour RAL 5009, azure blue Hook harness RAL 1007, daffodil yellow Load hook RAL 9005, deep black Lifting height and chain storage - 150 m hook path - without chain storage (chain storage unit mounted on the ground by the customer) Type of control Control Conventional contactor control control unit DSK 3-SP2 control switch Control line support hose (shortened) 1.5 m Other equipment features - Chain guide via pipe to chain storage - Microtherm (temperature contact) wrapped in the lift motor - protective cuff on the hook harness - 5.0 m (690V) connection cable documentation EU documents in accordance with the Machinery Directive |
Discover the superior quality and performance of the Demag DC-WindCC 10-350 1/1 H150 V24/6 690/50 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DC-WindCC 10-350 1/1 H150 V24/6 690/50 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DC-WindCC 10-350 1/1 H150 V24/6 690/50 :
At Onrion LLC , we offer the DC-WindCC 10-350 1/1 H150 V24/6 690/50 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DC-WindCC 10-350 1/1 H150 V24/6 690/50 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Demag products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
