Buy DFC01DB23 from Carlo Gavazzi in United States

BRAND	Carlo Gavazzi
Product	DFC01DB23
Description	OUTPUT SIGNAL 2 relays SETPOINTS 2, adjustable MONITORED VARIAB
Internal code	ONR249733
Weight	1
Technical specification	Monitoring Relays Frequency monitoring TypeDFC01 • Over and under frequency monitoring relay • Measures if power supply frequency is within set limits • Measures on own power supply • Separately adjustable upper/lower level on relative scale • Separately adjustable delay functions (0.1 to 30 s) • Output: 2 x 8 A SPDT relays • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 45 mm Euronorm housing • LED indication for relays, alarm and power supply ON Product Description Ordering key DFC 01 D B23 DFC01 is a precise frequen- cy monitoring relay. It moni- tors its own power supply. Overfrequencyandunder- frequency can be monitored separately with two indepen- dentsetpoints,delay times and relay outputs. The LED's indicate the state of the alarm and the output relay. Housing Function Type Item number Output Power Supply TypeSelection MountingOutput Supply: 24/48 VACSupply: 115/230 VAC DIN-rail2 x SPDT DFC 01 D B48DFC 01 D B23 InputSpecifications Input Own power supply A1, A2 or A2, A3 Measuring ranges Upper level Lower level Selectable by DIP-switches 2 Hz range+0.2 to +2.2 Hz -2.2 to -0.2Hz 50 Hz 50.2 to 52.2 Hz 47.8 to 49.8 Hz 60 Hz 60.2 to 62.2 Hz 57.8 to 59.8 Hz 10 Hz range+1 to +11 Hz-11 to -1 Hz 50 Hz 51 to 61 Hz39 to 49 Hz 60 Hz 61 to 71 Hz49 to 59 Hz Ranges Upper frequency level+10 to +110% of the selected range Lower frequency level-110 to -10% of the selected range Output Specifications Output2 x SPDT relays N.E. Rated insulation voltage 250 VAC Contact ratings (AgSnO2)µ Resistive loadsAC 1 8 A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 13 2.5 A @ 24 VDC Mechanical life≥ 30 x 106operations Electrical life ≥ 105operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency≤ 7200 operations/h Dielectric strength Dielectric voltage≥ 2 kVAC (rms) Rated impulse withstand volt.4 kV (1.2/50 µs) Hysteresis (frequency) 2 Hz range~ 0.05 Hz 10 Hz range~ 0.25 Hz Supply Specifications Power supplyOvervoltage cat. III Rated operational voltage(IEC 60664, IEC 60038) through terminals:A1, A2 or A3, A2 B48:24/48 VAC ± 15% 40 to 70 Hz, insulated B23:115/230 VAC ± 15% 40 to 70 Hz, insulated Rated operational power 5 VA

Discover the superior quality and performance of the Carlo Gavazzi DFC01DB23 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The DFC01DB23 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of DFC01DB23 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the DFC01DB23 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the DFC01DB23 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
