| BRAND | Frizlen |
| Product | FAQ3248004-3.7 |
| Description | Steel grid fixed resistor |
| Internal code | ONR3415895 |
| Weight | 93 |
| Custom code | 85332900 |
| Technical specification | steel lattice fixed resistance device, manufacturing tolerance +/- 10%, Ohm value change between cold and operating temperature approx. + 15%, for floor installation, in galvanised all-round sealed Sheet steel housing with safety grille at the bottom and top, without weather protection cover, connection to terminals in the device, clamps after disassembly accessible from the front cover, version according to list sheet T629, Dimensions according to drawing 16M0087 Frizlen Item Number: 32260 - Resistance, Electr. , Continuous power: 24 kW Resistance value: 3.7 ohms Protection class: IP 20 for hoist 1: max. 90 kW Resistance value: 3.7 ohms Continuous power (built-in): 40 kW (80 S05-0.047) Connection to terminals: 2 BK M8-25 Temp. switch: number/terminals: 1 pcs./ PK2 Switch card: 111961 Type plate: FRIZLEN Fixed resistor with special hole spacing LAT=425mm, with warning sign, with an additional terminal strip, with 2 additional perforated plate covers at the bottom |
Discover the superior quality and performance of the Frizlen FAQ3248004-3.7 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FAQ3248004-3.7 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FAQ3248004-3.7 :
At Onrion LLC , we offer the FAQ3248004-3.7 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the FAQ3248004-3.7 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Frizlen products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
ED=100/6 KW=16/13.5 OHM=18
(Frizlen Trade Item Number: 33832 - resistance, electric, continuous power: 2kW, resistance value: 15ohm, Termination: PK2)
Continuous power: 2000 W Resistance: 33 ohms (+/- 10% manufacturing tolerance) Embodiment according list sheet T116 Dimensions according dimensional drawing 11M0328
Fixed resistor in Flachau guide in the encapsulated aluminum housing, in IP 54, with 2 strands FEP AWG 14/19, 0.5 m long, dimensions, dimensional drawing by 13 M 0446, technical description to T316
GLAD 210x40-60 17748 R911275652
resistor
Frizlen Trade Item Number: 17748 - resistance, electrical drawing number continuous power resistance manufacturing tolerance Their devices Type / Specification wiring packing : 109-1039-2203-05 : 150 Watt : 60 ohms + 5% : DKCXX.3-040-7 : Radox AWG18 (red), 600 V, 150 ° C : Socket B2,8-1 protection IP40
(Continuous power: 460 Watt; resistance: 18 ohms, Connection with 4 additional fixing holes 8 mm, Hole size 63x322 mm)
POTANSISIYOMETRE 2.5 KOHM 30 W TEK TURLU
Cemented wire rotational resistance, type power 50 W, resistance value 82 Ohm, resistor tolerance +/- 10%, with flat connectors 4,8x0,8, axial length of 35 mm from the mounting face execution by List sheet T223,
POTENTIOMETER
[Continuous power: 16 W Resistance of 1.0 ohms (+/- 10% manufacturing tolerance) Embodiment according list sheet T223 Dimensions according dimensional drawing 12M-0802-00-001 FRIZLEN Article ID No. 18923]
Continuous power: 15 W Resistance: 1.0 ohms (+/- 10% manufacturing tolerance) Embodiment according AK0568 through rotatable FRIZLEN Article ID No. 13734
Frizlen Trade Item Number: 13764 - resistance, electrical Continuous power: 30 watts Resistance of 4.7 ohms
Rotational resistance wire type power 50 W, resistance value 220 ohms, Embodiment according list sheet T223, Fa. Frizlen Art.Id.Nr. 16995
11302 - Resistor, electr./63 kW/2.1 Ohm/ IP 23/ 250 kW/15 % ED/120 sec/2 BK M10-25/ 100 s/ Strip for cable entry point with 3x diameter 32mm perforation
braking resistance
resistor
resistor
RESISTOR
resistor
