BRAND | Hopf |
Product | FG6875AC00LAN-7273 // 6875AC |
Internal code | ONR4623530 |
Custom code | 91069000 |
Technical specification | GPS DIN Rail TimeServer 6875AC in extended DIN Rail Housing, Typ 6 dimensions 175(D)x135(W)x105(H)mm consisting of: FG6875AC00 GPS DIN Rail Module 6875AC with: • Input voltage: - 85-264V AC and 100-250V DC - Connection via 3pole pluggable screw terminal incl. housing • 3 optical coupler pulse outputs • Serial interface 1: RS232 level • Serial interface 2: freely selectable in RS232/RS422/RS485 level • Logical outputs at the interfaces: hopf serial standard-strings, IRIG-B 00x, PPS-pulse, DCF77-pulse • hmc Remote-Software (hopf Management Console) for configuration and management via RS232 interface supporting below operating systems: - Microsoft® Windows® NT/2000/XP/VISTA/7 (32/64 Bit) - Microsoft® Windows® Server 2003/2008 (32/64 Bit) - Linux® (32/64 Bit) - Oracle® Solaris SPARC/x86 - IBM AIX® (version 5.2 and higher) - HP-UX 11i (supporting RS232 only for PA-RISC architecture) • Simulation output freely programmable: - IRIG-B 12x - IEEE 1344 - AFNOR NF S87-500 - DCF77 antenna simulation (77.5kHz) • In housing (130(D)x100(W)x105(H)mm) for 35mm rail mounting (DIN EN 50 022) • Software and manual on CD • 2m programming cable KA6870 FG7273DIN-RAIL NTP/SINEC H1 TimeServer Board for DIN Rail Modules with one(1) LAN Interface: • 10/100Base-T Interface (auto sensing) for ETHERNET IEEE 802.3 - Connection via RJ45-connector • Supported Time Protocols: - NTP/SNTP Vers. 4.2.x (RFC 5905) - DAYTIME (RFC 867) - TIME (RFC 868) - SINEC H1 Time Datagram • System Monitoring/Alarming (syslog, email, SNMP) • SNMP MIB II, hopf Enterprise MIB • USB Port • Status LEDs and Default Push-Button • Front Panel for DIN Rail housing * ONLY IN COMBINATION WITH A DIN RAIL MODULE |
Discover the superior quality and performance of the Hopf FG6875AC00LAN-7273 // 6875AC with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FG6875AC00LAN-7273 // 6875AC is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FG6875AC00LAN-7273 // 6875AC :
At Onrion LLC , we offer the FG6875AC00LAN-7273 // 6875AC at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the FG6875AC00LAN-7273 // 6875AC ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Hopf products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
