| BRAND | Frizlen |
| Product | FKHZ5660604-28/630 |
| Description | Resistor |
| Internal code | ONR3390579 |
| Weight | 12 |
| Custom code | 85332900 |
| Technical specification | Frizlen item number: 30470 Drawing number: 13M0540 Fixed resistors in encapsulated design, protection class IP 54, Dimensions as measured diagram 13M0540, with the following resistor installation: a.) permanent resistor 28 ohms, for Gs motor 3.7 kW, 750 V DC, IN=9.7 A, IA=26 A, wired to 2 terminals, terminal designation 1/2 and ohm value, consisting of 5 units of encapsulated Flat resistors in anodized aluminum housing our type GWAD520x80-140, Parallel b.) field resistor 630 Ohm, 400 W, wired to 2 terminals, Terminal designation 1/2 and ohm value, consisting of 1 pc. GWAD520x80-630 Terminals in the attached terminal box with protection class IP54, with 3 M12 cable glands, with 4 silicone-insulated strands L1-L4 Fabr.Omerin, Type Y 300S NF F63/Y1500S NF F63-826, 4 mm², with 1 label “hot component” on each side, according to customer drawings 2235567615-2235567620, all internal cables in the terminals connected with Ferrules |
Discover the superior quality and performance of the Frizlen FKHZ5660604-28/630 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FKHZ5660604-28/630 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FKHZ5660604-28/630 :
At Onrion LLC , we offer the FKHZ5660604-28/630 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the FKHZ5660604-28/630 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Frizlen products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Tubular fixed resistor
ED=100/6 KW=16/13.5 OHM=18
(Frizlen Trade Item Number: 33832 - resistance, electric, continuous power: 2kW, resistance value: 15ohm, Termination: PK2)
Continuous power: 2000 W Resistance: 33 ohms (+/- 10% manufacturing tolerance) Embodiment according list sheet T116 Dimensions according dimensional drawing 11M0328
Fixed resistor in Flachau guide in the encapsulated aluminum housing, in IP 54, with 2 strands FEP AWG 14/19, 0.5 m long, dimensions, dimensional drawing by 13 M 0446, technical description to T316
GLAD 210x40-60 17748 R911275652
resistor
Frizlen Trade Item Number: 17748 - resistance, electrical drawing number continuous power resistance manufacturing tolerance Their devices Type / Specification wiring packing : 109-1039-2203-05 : 150 Watt : 60 ohms + 5% : DKCXX.3-040-7 : Radox AWG18 (red), 600 V, 150 ° C : Socket B2,8-1 protection IP40
(Continuous power: 460 Watt; resistance: 18 ohms, Connection with 4 additional fixing holes 8 mm, Hole size 63x322 mm)
POTANSISIYOMETRE 2.5 KOHM 30 W TEK TURLU
Cemented wire rotational resistance, type power 50 W, resistance value 82 Ohm, resistor tolerance +/- 10%, with flat connectors 4,8x0,8, axial length of 35 mm from the mounting face execution by List sheet T223,
POTENTIOMETER
[Continuous power: 16 W Resistance of 1.0 ohms (+/- 10% manufacturing tolerance) Embodiment according list sheet T223 Dimensions according dimensional drawing 12M-0802-00-001 FRIZLEN Article ID No. 18923]
Continuous power: 15 W Resistance: 1.0 ohms (+/- 10% manufacturing tolerance) Embodiment according AK0568 through rotatable FRIZLEN Article ID No. 13734
Frizlen Trade Item Number: 13764 - resistance, electrical Continuous power: 30 watts Resistance of 4.7 ohms
Rotational resistance wire type power 50 W, resistance value 220 ohms, Embodiment according list sheet T223, Fa. Frizlen Art.Id.Nr. 16995
11302 - Resistor, electr./63 kW/2.1 Ohm/ IP 23/ 250 kW/15 % ED/120 sec/2 BK M10-25/ 100 s/ Strip for cable entry point with 3x diameter 32mm perforation
braking resistance
resistor
resistor
