BRAND | Foxboro (by Schneider Electric) |
Product | IDP10-D20C21F-M2L1C1Y |
Internal code | ONR4671359 |
Technical specification | TRANSMITTER; DIFFERENTIAL PRESSURE; MEASUREMENT RANGE: -840 TO 840 IN H2O; CALIBRATION RANGE: 0 TO 600 IN H2O; OUTPUT SIGNAL: 4-20 MA DC (FOXCOM PROTOCOL); SUPPLY: 24 VDC (2-WIRE); SENSOR MATERIAL: Co-Ni-Cr; PROCESS CONNECTION: TRADITIONAL FLANGE; FLANGE MATERIAL: 316 SS; ELECTRICAL CONNECTION: 1/2 INCH NPT; HOUSING MATERIAL: ALUMINIUM; DIGITAL INDICATOR WITH PUSH BUTTONS & WINDOW COVER; ACCESSORIES: STAINLESS STEEL MOUNTING BRACKET WITH STAINLESS STEEL BOLTS, 1/2 IN NPT PROCESS CONNECTORS - 2 NO.S (MOC-316 SS); MANUFACTURER: FOXBORO; MODEL: IDP10 SERIES; PART NUMBER: IDP10-D20C21F-M2L1C1Y OR ANY EQUIVALENT FROM APPROVED LIST; APPROVAL: FM, IP66 & NEMA TYPE 4X; MANUFACTURERS DATA SHEET,CERTIFICATE OF CALIBRATION & HYDROTEST REPORT REQUIRED; DOCUMENTATION SUCH AS OPERATION,INSTALLATION,INSTRUCTION & MAINTENANCE MANUALS REQUIRED; MEASUREMENT RANGE SHOULD BE EMBOSSED ON THE TRANSMITTER TAG & SEPERATE STEEL TAG FOR CALIBRATION RANGE TO BE PROVIDED. |
Discover the superior quality and performance of the Foxboro (by Schneider Electric) IDP10-D20C21F-M2L1C1Y with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The IDP10-D20C21F-M2L1C1Y is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of IDP10-D20C21F-M2L1C1Y :
At Onrion LLC , we offer the IDP10-D20C21F-M2L1C1Y at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the IDP10-D20C21F-M2L1C1Y ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Foxboro (by Schneider Electric) products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
