| BRAND | Wika |
| Product | IPT-20 |
| Internal code | ONR4901590 |
| Technical specification | Specifications according to data sheet: PE 86.06 Measuring range: adjustable with turn down up to 100 : 1 Process connection type: Standard connection with pressure port Electrical approval: IECEx/ATEX Ignition protection type: Ex i - intrinsically safe Zone: Zone 0 gas [Ex ia IIC T6...T1 Ga] Housing material: Plastic double chamber Case version: compact/ IP66/IP67; NEMA 4X Digital Display: with integrated indicating/adjustment module (top) Output signal: 4...20 mA, 2-wire, HART Electrical connection: M20x1,5 / cable gland brass nickel plated (ø5-9mm) Measuring range: 0...40 bar gauge Accuracy: 0.1 % of span process connection form: Gauge connection open Process connection / wetted parts: Thread G½B, EN837; gauge connection / 316L Sealing: without, -40 ... +105°C Clean specification: without Filling of sensor: synthetic oil Certification sterile processes: without Wetted parts: stainless steel Unit scaling: without Density unit: kg/dm³ Sensor principle: piezoresistiv |
Discover the superior quality and performance of the Wika IPT-20 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The IPT-20 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of IPT-20 :
At Onrion LLC , we offer the IPT-20 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the IPT-20 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
SWITCH,PRESSURE
analog pressure sensor
Pressure switch
PCS2MB: MAX .PRESSURE:10 BAR, PROOF PRESSURE:40 BAR
0.8 to 6 Bar
PCS2MB: PRESSURE:10 BAR, PROOF PRESSURE:40 BAR
1.6 to 10 Bar
1400s937 03 2014 prüf nummer 14 101 pressure gauge with alarm contacts typ 212.20.100 kont 821.1 0-10bar umax 250vac pmax 30w 50va KI 1.0
Switch gauge with alarm contact
PGS23.160 821.3 PMAX : 20 W , 20 VA , UMAX : 250 V , IMIN : 20 MA FLANGE : PM2 , 150 LB , B16.3 A/
Switch gauge with alarm contact
PRESSURE GAUGE FOR GAS 3500 - 4000 PSI, DIAMETER 2 INCH
Pressure gauge for gas 3500 - 4000 PSI, diameter 2 inch, connect with air at the bottom, having liquid inside, tube diameter 1/4 npt, graduation 100 psi
PRESSURE GAUGE FOR GAS 3500-4000 PSI, DIAMETER 2 AND 1/2 INCH
Pressure gauge for gas 3500 - 4000 PSI, diameter 2 and 1/2 inch (63.5 mm), connect with air at the back, having liquid inside, tube diameter 1/4 npt, graduation 100-200 psi
PRESSURE GAUGE WITH LIQUID FILLING , 0-1000 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-1000 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING , 0-1200 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-1200 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING , 0-30 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 100 mm WITH LIQUID FILLING , 0-30 BAR
PRESSURE GAUGE WITH LIQUID FILLING , 0-500 MM H2O
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING , 0-500 MM H2O
PRESSURE GAUGE WITH LIQUID FILLING, 0-100 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 160 mm WITH LIQUID FILLING, 0-100 BAR
PRESSURE GAUGE WITH LIQUID FILLING, 0-1000 M BAR MODEL; 233.50
Lower back mount LBM, surface mounting flange , No minal size OD 100 mm WITH LIQUID FILLING, 0-1000 M
PRESSURE GAUGE WITH LIQUID FILLING, 0-16 BAR MODEL 232.30
Lower mount LM, surface mounting flange , Nominal size OD 100 mm WITH LIQUID FILLING, 0-16 BAR
PRESSURE LOWER MOUNT LM,SURFA MOUNTING FLANGE ,NOMINAL SIZE OD 160 MM WITH LIQUID FILLING, 0-30 BAR
GAUGE WITH LIQUID FILLING, 0-30 BAR
Göstergeli elektronik basınç ölçer 1 M two switching outputs, (PNP) only with M12x1 plug, 4-pin N 2 B 3 C4 4 GD G 1/2 B NC 5 M4 4-pin locking plug M12x1 IP 67 NC 6 Z Without NC 7 Z Without NC
LENGHT 150MM, THICKNESS 3MM, COMPLETE WITH TERMINAL HEAD
