BRAND | GSR |
Product | G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) |
Internal code | ONR5001180 |
Custom code | 84818071 |
Technical specification | G027.000786.090.002.039 for connection to 230V 50-60HZ Reference B27050401.322XX consists of: 027.000786 2/2-way solenoid valve Type: B2705/0401/.322 Control type: positively controlled, required delta p: 0 bar Construction: membrane design Function: NC - closed without current Connection: DN40 PN16 flange in accordance with EN 1092-1, form B1 Pressure: 0-10 bar Medium temperature: -10°C/+80°C Ambient temperature: -10°C/+35°C Viscosity max.: 22 mm²/s Material (housing): cast iron EN-JL 1040 Material (internal parts): 2.0401 brass/ 1.4104 stainless steel Seal: NBR Installation position: upright drive Note: with adjustable damping as standard B0051.000413 magnetic coil Type: .322 (K0513239) Voltage: 205V DC Dust/water protection: IP65 Power: 30W Duty time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040.000039 Appliance plug with bridge rectifier and varistor protection circuit Cable fitting: M20x1.5 connectable cables: Ø4.5-11mm max.1.5mm² .: For connection in the device plug, only multi-wire conductors after .: Use VDE 0295 class 2 or better Standard: EN 175301-803 Form A/ISO 4400 Case color: Gray |
Discover the superior quality and performance of the GSR G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) :
At Onrion LLC , we offer the G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the G027.000786.090.002.039 / B27050401.322XX / .322 (K0513239) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply GSR products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
