BRAND | LAIPPLE KEB |
Product | K53AV DA160MB4 B07 EI02 TW F |
Description | Bevel Gear Motor |
Internal code | ONR4291995 |
Technical specification | Output speed: 115 rpm Torque: 915Nm Transmission coefficient: 1.45 Gearbox: translation: 15.37 foot design Output shaft with feather key Ø50x100 bleed valve Connection side: R Lubricant: 1.8 l CLP VG220 mineral oil Motor: three-phase motor IE3 Rated power: 11.0kW Engine speed: 1760 rpm Voltage/frequency: Y 460V 60Hz Rated current: 17.3A cosφ: 0.86 Insulation class: 155 Protection class: IP54 brake B07, 100Nm, 24VDC EI02 - incremental encoder 2048 pulses/U, 4.5-32VDC, push-pull (HTL) signals A, B.0 and inverted signal plug M23-12pin, position 315A, without mating plug Engine protection: PTC temperature sensor external ventilation Y 400 50Hz/Y 460V 60Hz, 0.37/0.32A Motor connection: terminal box 2xm40+1xM16, position 0A Color: normal, RAL7031 blue-grey Installation position: M1 |
Discover the superior quality and performance of the LAIPPLE KEB K53AV DA160MB4 B07 EI02 TW F with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The K53AV DA160MB4 B07 EI02 TW F is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of K53AV DA160MB4 B07 EI02 TW F :
At Onrion LLC , we offer the K53AV DA160MB4 B07 EI02 TW F at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the K53AV DA160MB4 B07 EI02 TW F ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply LAIPPLE KEB products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
