BRAND | Uraca |
Product | KD724-C |
Description | pump |
Internal code | ONR4912217 |
Custom code | 84135069 |
Technical specification | operating point 1: 468 l/min. at 70 bar operating point 2: 618 l/min. at 52 bar operating point 3: 367 l/min. at 90 bar for exchange of previous delivery PI-11901087 HP1 Medium handled demineralized water, free from gas without chemical additions Operating temperature 3 to + 40 °C Density on suction side 1000 g/dm3 pH-value approx. 6,5 – 7,5 Solids Fibre particles, negligible Quantity of solids max. 20 ppm Size of solid particles max. 50 m Technical data Pump model KD724-G integrated gear box i = 4,20 Plunger diameter 75 mm Number of plungers 3 Stroke 85 mm Operating data min. OP 1 OP 2 OP 3 Pressure at suction connection of working pump 3 3 - 6 3 - 6 3 - 6 bar Discharge pressure 70 52 90 bar Safety valve set pressure 100 100 100 bar Differential pressure ∆p for drive design 67 49 87 bar Capacity 108 468 618 367 l/min Pump speed 100 432 571 339 min-1 Mean plunger speed 0,28 1,23 1,62 0,96 m/s Power required at pump shaft * at 468 l/min and 67 bar ∆p 57 kW at 618 l/min and 49 bar ∆p 55 kW at 367 l/min and 87 bar ∆p 58 kW Recommended motor rating at 1816 min-1, 468 l/min, 67 bar ∆p ≥ 62 kW at 2398 min-1, 618 l/min, 49 bar ∆p ≥ 60 kW at 1424 min-1, 367 l/min, 87 bar ∆p ≥ 63 kW Motor speed 420 1816 2398 1424 min-1 |
Discover the superior quality and performance of the Uraca KD724-C with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The KD724-C is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of KD724-C :
At Onrion LLC , we offer the KD724-C at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the KD724-C ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Uraca products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Sheath ring with O-ring TFMI 45-52.2-3.8 - race d45 / 47x3.8 / O-ring d46, 2x3
TEST PUMP
Filter for pump
SEALING RINGS
0-Ring d50,39x3,53 Nr.226
Support ring 511109-226 dSO, 8 / 57x0.7
0-Ring d31,34x3,53 Nr.218
CRANKPIN SHELL
P/N: BG004077 Type: EP601 W/100
Electrical Test Pump
gasket kit
sealing ring
Sealing ring D38/Soxlo
0-Ring dlO,82x1,78 Nr.013
Sealing ring d27/32x2
Kit Chassis for Electric Test Purnpe URACA EP6O1
tube
Hose line
pump
Manual test pump complete
pump plunger
stuffing box
pressure collector
valve body pump
pump suction manifold
