Buy LI100P0-Q25LM0-ELIUPN8X3-H1151 from Turck in United States

BRAND Turck
Product LI100P0-Q25LM0-ELIUPN8X3-H1151
Description Inductive Linear Position Sensor IO-Link
Internal code ONR766594
Weight 1
Technical specification Order number: 1590017 Measuring principle Inductive General data Measuring range 100 mm Resolution 0.002 mm/16 bit Nominal distance 1.5 mm Blind zone a 29 mm Blind zone b 29 mm Reproducibility ≤ 18 µm Linearity deviation ≤ 0.12 % f.s. Temperature drift ≤ ± 0.003 % / K Hysteresis not applied Electrical data Operating voltage 15…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes Wire breakage/Reverse polarity protection yes / Complete Communication protocol IO-Link Output function 5-pin, NO/NC, PNP/NPN, analog output Output 1 Switching output or IO-Link mode Output 2 Analog or switching output Voltage output 0…10 V Current output 4…20 mA programmable via IO-Link Load resistance voltage output ≥ 4.7 kΩ Load resistance current output ≤ 0.4 kΩ Sample rate 1000 Hz Current consumption < 50 mA IO-Link specification V 1.0 Programming FDT / DTM Process data width 16 bit Frame type 2.2 Included in the SIDI GSDML Yes Mechanical data Design Profile, Q25L Dimensions 158 x 35 x 25 mm Housing material Aluminum/plastic, PA6-GF30, Anodized Active area material Plastic, PA6-GF30 Electrical connection Connector, M12 × 1 Environmental conditions Ambient temperature -25…+70 °C Vibration resistance 55 Hz (1 mm) Shock resistance 30 g (11 ms) Protection class IP67 MTTF 138 years acc. to SN 29500 (Ed. 99) 40 °C Power-on indication LED, Green Measuring range display multifunction LED, green, yellow, yellow flashing

         Discover the superior quality and performance of the Turck LI100P0-Q25LM0-ELIUPN8X3-H1151 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The LI100P0-Q25LM0-ELIUPN8X3-H1151 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of LI100P0-Q25LM0-ELIUPN8X3-H1151 :

  • High Performance: Engineered to deliver exceptional results.
  • Durable Construction: Built with high-quality materials for long-lasting use.
  • Innovative Design: Incorporates the latest technology for enhanced efficiency.
  • Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the LI100P0-Q25LM0-ELIUPN8X3-H1151 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

  • Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
  • Competitive Prices: We offer some of the best prices in the market.
  • Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
  • Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the LI100P0-Q25LM0-ELIUPN8X3-H1151 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Turck products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
