Buy LI600P0-Q25LM0-ELIUPN8X3-H1151 from Turck in United States

BRAND	Turck
Product	LI600P0-Q25LM0-ELIUPN8X3-H1151
Description	Inductive linear position sensor — IO-Link
Internal code	ONR765653
Weight	1
Technical specification	ID:1590607 Measuring principle Inductive General data Measuring range 600 mm Resolution 0.009mm/16 bits Nominal distance 1.5 mm blind area a 29 mm blind zone b 29 mm Repeatability ≤ 36 µm Linearity deviation ≤ 0.04 % f.s. Temperature deviation ≤ ±0.003 % / K Hysteresis is not applied electrical data Operating voltage 15…30 VDC Stray surge ≤ 10 % Uss Insulation test voltage ≤ 0.5 kV Short circuit protection yes Wire break/Reverse polarity protection yes / Complete Communication protocol IO-Link Output function 5-pin, NO/NC contact, PNP/NPN analog exit Output 1 Switching output or IO-Link mode Output 2 Analog or switching output Voltage output 0…10 V Current output 4…20 mA programmable via IO-Link Load resistor voltage output ≥ 4.7 kΩ Load resistor current output ≤ 0.4 kΩ Sample rate 1000 Hz Current consumption < 50 mA IO-Link Features V 1.0 Parameterization FDT / DTM Process data width 16 bits Frame type 2.2 SIDI is included in GSDML Yes Mechanical data Design Profile, Q25L Dimensions 658 x 35 x 25 mm Housing material Aluminum/plastic, PA6-GF30, anodized Active site material plastic, PA6-GF30 Electrical connection Connectors, M12 × 1 Ambient conditions Ambient temperature -25…+70 °C Vibration resistance 55 Hz (1 mm) Impact resistance 30 g (11 ms) IP Rating IP67 Conforming to MTTF 138 year SN 29500 (Ed. 99) 40 °C Power-on indicator LED, green Measuring range display multifunctional LED, green, yellow, yellow blink

Discover the superior quality and performance of the Turck LI600P0-Q25LM0-ELIUPN8X3-H1151 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The LI600P0-Q25LM0-ELIUPN8X3-H1151 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of LI600P0-Q25LM0-ELIUPN8X3-H1151 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the LI600P0-Q25LM0-ELIUPN8X3-H1151 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the LI600P0-Q25LM0-ELIUPN8X3-H1151 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Turck products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
