| BRAND | Ascon |
| Product | M3-5106-0020 |
| Description | Control thermostat |
| Internal code | ONR4585142 |
| Technical specification | thermostat series M3, M3-5106-0200/9999 (unconfigured) Supply voltage: 18... 28 V 48/63 Hz and 20... 30 Vdc output OP1/3: relay (2A/250V normally open) output OP2: relay (2A/250V normally open) or logic (0/5VDC, 30mA) not electrically isolated adjustable via internal jumpers Output OP4: not available Serial interface: none Interface protocol: without Can be freely configured as follows: input: PT100; thermocouple L, J, T, K, S; 0 (10)... 50 mV DC, 0 (4)... 20mA via shunt OP1/OP3 control or alarm output Output OP2: control or alarm output Control: ON/OFF or PID, heating or cooling, Heating/cooling Assignment: 1 output to control and 2 outputs as alarm O. 2 outputs for control and 1 output as alarm Special features: with integrated transmitter supply Options: current transformer input, transmitter supply, Analog output (PV), serial interface |
Discover the superior quality and performance of the Ascon M3-5106-0020 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The M3-5106-0020 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of M3-5106-0020 :
At Onrion LLC , we offer the M3-5106-0020 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the M3-5106-0020 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ascon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
