| BRAND | Rsf Elektronik |
| Product | PN: 1347668-49, Type: MSA 650.23 |
| Description | measuring system |
| Internal code | ONR3685145 |
| Weight | 1 |
| Technical specification | Interval 20 μm; Accuracy class ± 10 μm / m; RI 13:25 mm from the left; Supply: +12 V; Output: rectangular Signals 12 V; CC 014: K1, 3 m cable, connector L70; Measuring length 320 mm |
Discover the superior quality and performance of the Rsf Elektronik PN: 1347668-49, Type: MSA 650.23 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PN: 1347668-49, Type: MSA 650.23 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PN: 1347668-49, Type: MSA 650.23 :
At Onrion LLC , we offer the PN: 1347668-49, Type: MSA 650.23 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PN: 1347668-49, Type: MSA 650.23 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rsf Elektronik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
081-05728601011 MSA 654 replaced by D22100005480 MSA 654.23 D2210
Interval 20 microns; Accuracy ± 10 microns / m; without reference mark; Supply: +5 V; Output: rechteckf. Signals 5 V; CC 054: K2, 2 m cables, connectors L70; gauge length 152 mm;
081-9263990101 old- replaced by new MSA 650.23
lineal encoder, typ MSA 665
MSA 670.13
MSAA 665 400mm electronic ruler
encoder
AUSFUHRUNG WIE SER.-NR: 18-5093 8/5X
Subdividing Electronics ZE-5
Incremental length measuring scanning unit MSA measurement system KP 371.63 Interval 20 microns, 5-fold Accuracy ± 5 microns / m RI 50: Distance-coded Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC 408: K1, 1 m cable in Metallschl, L121. Measuring length 920 mm
Pos. 01 measuring system MSA 650.24; interval 40 microns; Accuracy ± 10 microns / m; RI 02: center of the gauge length; Supply: +12 V; Output: rechteckf. Signals 12 V; CC 122: K1, 3 m Metallgefl cable, plug L70;. gauge length 370 mm;
MSA 654.23 measurement system
Pos. 01 Incremental length measuring scanning MSA350.23 measuring system MSA 350.23 lt. Datasheet D538D interval 20 microns Accuracy ± 10 microns / m RI 01: 20 mm from left Supply: + 10-30 V Output: rechteckf. signals 10-30V CC 999: Cable / lt plug data sheet. measuring length 180 mm
ML:110mm. MSA671.24
D649D00D0901 MEßSYSTEM MSA 650.24 LT. DATENBLATT D649D
Interval 40 microns; Accuracy ± 10 microns / m; without reference mark; Supply: +12 V; Output: rechteckf. Signals 12 V; CC D09: K1, 0.3 m cables, connectors FB51; occupancy lt D522129. gauge length 50 mm;
(Incremental length measuring MSA690.63 MSA measurement system 690.63-2 Interval 20 microns, 5-fold Accuracy ± 5 microns / m RI 07: 35 mm from left and right Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC A47: K1, 3 m UHF cable connector LD15 Occupancy lt Z. 44,050 Switching signals: open collector - active high Measuring length 770 mm with short-legged sealing lips)
INKREMENTALES LÄNGENMEßSYSTEM ABTASTEINHEIT MSA654.24
Measuring system MSA 654.24 interval 40 microns Accuracy ± 10 microns / m RI 02: center of the gauge length Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC 403: K2, 0.5 m in cable Metallschl, SA120. gauge length 220 mm
INKREMENTALES LÄNGENMEßSYSTEM MSA665.B3
MSA measurement system 665.B3 interval 20 microns Accuracy ± 5 microns / m RI 02: center of the measuring length supply: ± 12 V Output: Sinusoidal. Signals 16 Vss CC 903: K2, 0.5 m Metallgefl cable, plug L70. gauge length 220 mm
Datasheet D2210 Gauge length 72 mm; interval 20 microns;
Datasheet D2210; Gauge length 152 mm; Interval 20 microns;
interval 40 microns; Accuracy ± 10 microns / m; RI 02: center of the gauge length; Supply: +12 V; Output: rechteckf. Signals 12 V; CC 122: K1, 3 m Metallgefl cable, plug L70;. gauge length 1040 mm;
MEßSYSTEM MSA 650.24 (CODE : C0T460212229)
measuring system MSA 650.24 interval 40 microns Accuracy ± 10 microns / m RI 02: center of the gauge length Supply: +12 V Output: rechteckf. Signals 12 V CC 122: K1, 3 m Metallgefl cable, plug L70. measuring length 520 mm
Measuring system
Scanning MS50.66 (ID: 43854030) Interval 200 microns, 5-fold with reference mark Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC A88: 9 m cables, connectors L120 RSF art. No. LH46001A8800
head MS lt 50.76 M. Datasheet D279B interval 200 microns, 10-fold without reference mark Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC E17: 1.3 m cables, connectors KD9 occupancy lt Z:. 44 729 B
ruler
(Encoder,grating pitch 20 µm; accuracy ±10 µm/m; RI 02: center of the measuring length; supply: +5 V; output: square wave signals 5 V; CC 122: K1, 3 m cable with braiding, conn. L70; measuring length 720 mm;)
