| BRAND | Rsf Elektronik |
| Product | MSA 654 |
| Internal code | ONR4963630 |
| Technical specification | ML 80mm Intervall 40um U+5V RI CODE B2 Signal _∏_ 5V |
Discover the superior quality and performance of the Rsf Elektronik MSA 654 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MSA 654 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MSA 654 :
At Onrion LLC , we offer the MSA 654 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the MSA 654 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rsf Elektronik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
(Incremental length measuring MSA690.63 MSA measurement system 690.63-2 Interval 20 microns, 5-fold Accuracy ± 5 microns / m RI 07: 35 mm from left and right Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC A47: K1, 3 m UHF cable connector LD15 Occupancy lt Z. 44,050 Switching signals: open collector - active high Measuring length 770 mm with short-legged sealing lips)
INKREMENTALES LÄNGENMEßSYSTEM ABTASTEINHEIT MSA654.24
Measuring system MSA 654.24 interval 40 microns Accuracy ± 10 microns / m RI 02: center of the gauge length Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC 403: K2, 0.5 m in cable Metallschl, SA120. gauge length 220 mm
INKREMENTALES LÄNGENMEßSYSTEM MSA665.B3
MSA measurement system 665.B3 interval 20 microns Accuracy ± 5 microns / m RI 02: center of the measuring length supply: ± 12 V Output: Sinusoidal. Signals 16 Vss CC 903: K2, 0.5 m Metallgefl cable, plug L70. gauge length 220 mm
Datasheet D2210 Gauge length 72 mm; interval 20 microns;
Datasheet D2210; Gauge length 152 mm; Interval 20 microns;
interval 40 microns; Accuracy ± 10 microns / m; RI 02: center of the gauge length; Supply: +12 V; Output: rechteckf. Signals 12 V; CC 122: K1, 3 m Metallgefl cable, plug L70;. gauge length 1040 mm;
MEßSYSTEM MSA 650.24 (CODE : C0T460212229)
measuring system MSA 650.24 interval 40 microns Accuracy ± 10 microns / m RI 02: center of the gauge length Supply: +12 V Output: rechteckf. Signals 12 V CC 122: K1, 3 m Metallgefl cable, plug L70. measuring length 520 mm
Measuring system
Scanning MS50.66 (ID: 43854030) Interval 200 microns, 5-fold with reference mark Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC A88: 9 m cables, connectors L120 RSF art. No. LH46001A8800
head MS lt 50.76 M. Datasheet D279B interval 200 microns, 10-fold without reference mark Supply: +5 V Output: rechteckf. Signals via Line Driver 5 V CC E17: 1.3 m cables, connectors KD9 occupancy lt Z:. 44 729 B
ruler
(Encoder,grating pitch 20 µm; accuracy ±10 µm/m; RI 02: center of the measuring length; supply: +5 V; output: square wave signals 5 V; CC 122: K1, 3 m cable with braiding, conn. L70; measuring length 720 mm;)
Incremental length measurement system
MSA 650.63 (Art.Nr.: C0436G501405)
Incremental length measuring system MSA650.63
ML 920mm R102 Interval 20 microns Accuracy ± 5 microns / m
(Signals rechteckf 5 V CC 049: measurement system, interval 20 microns; Accuracy ± 10 microns / m; without reference mark;:; +5 V supply output. K1, 2 m cables, connectors L70; gauge length 72 mm)
(Signals rechteckf 5 V CC 054: measurement system, interval 20 microns; Accuracy ± 10 microns / m; without reference mark;:; +5 V supply output. K2, 2 m cables, connectors L70; gauge length 152 mm)
(Measuring system, interval 20 microns, 5-fold; Accuracy ± 5 microns / m; RI 02: center of the gauge length; Supply: +5 V; output: 5V rechteckf signals; CC. 269: K1, 2.3 m cable, plug L70; gauge length 122 mm)
(Interval 20 microns Accuracy ± 3 microns / 0,5m RI 23: 42.5 mm from left and right Supply: ± 5 V Output: Sinusoidal. Vss signals 5 CC 999: cable / connector Measuring length 135 mm)
Measuring system - · interval 10 microns; · Accuracy ± 2 microns / m; · RI 07: 35 mm from left and right; · Supply: +5 V; · Output: Sinusoidal. 7-16 .mu.Ass signals; · CC 613: K1, 4 m cables, connectors L91; · Measuring length 270 mm;
Enclosed Linear Encoder
