BRAND | RTK Regeltechnik |
Product | MV 5274, DN 20 |
Description | modulating valves |
Internal code | ONR4745009 |
Custom code | 84818059 |
Technical specification | Engine Control Valve - MV 5274 Series in three-way shape for mixing, with short B-flange Nominal diameter DN 20, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic/Anstrom.: linear/- mixing cone, metallic sealing Kvs value = 6 m³/h, stroke 15 mm seat diameter 32 mm Surface treatment with zinc dust primer max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 30E-074 actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm/s, stroke 15 mm Protection class IP 65 - additional limit switches (2 pieces) |
Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - MV 5274, DN 20 modulating valves number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
