| BRAND | Wika |
| Product | PGS43.100 |
| Internal code | ONR4722760 |
| Technical specification | 14605913 LM-F50 400 mbar 1/2 NPT Reed switch model 851.3 plug sidewise Connection location: lower mount Case: with pressure blowout disk class 1.6 Case filling fluid: Silicon oil M50 Diaphragm Material: Inconel 718 (2.4668) Sealing of pressure chamber: FPM Process connection: 1/2 NPT Overpressure safety: 5 x Full scale value, max 40 bar Window: laminated safety glass Case material: Stainless steel 316TI Ingress protection: IP 65 Permissible medium temperature: -20 ... +100 °C (-4 ... +212 °F) Permissible ambient temperature: -20 … +60 °C Pressure Gauge Standard: International (standard Europe) *WIKA* Serial number *...* Test report 2.2 per EN 10204 Certificate Language: English and French Certificate for: pressure gauge Accuracy certificate: Certification of class and accuracy |
Discover the superior quality and performance of the Wika PGS43.100 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PGS43.100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PGS43.100 :
At Onrion LLC , we offer the PGS43.100 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PGS43.100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Göstergeli elektronik basınç ölçer 1 M two switching outputs, (PNP) only with M12x1 plug, 4-pin N 2 B 3 C4 4 GD G 1/2 B NC 5 M4 4-pin locking plug M12x1 IP 67 NC 6 Z Without NC 7 Z Without NC
LENGHT 150MM, THICKNESS 3MM, COMPLETE WITH TERMINAL HEAD
R5502 -1-C1E-BK-E160GZ-ZZZ DIAL-T-1AZ1ZZZZZ
Bimetallic thermometer, chemical version Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: R 5502, initial size 100, of connection radial Design of connection: 1 Plain stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: plain, without thread Stem diameter: 10 mm Installation length L1: 160 mm Window: Instrument glass Connection position: bottom (radial) Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1
RANGE: -1BAR ~ 1.5 BAR O/P SIGNAL: 4-2MA/O-10VDC MODEL: S-10
VACUUM TRANSMITTER
(Druckmesserumformer for general applications)
Pressure Transmitter,Output: 4 - 20mA 2 wire @ 24 V DC, Electrical Connection: DIN Plug,Accuracy:Standard, Oxygen Compatible
S-10-A-PBK-NB-ZGA4ZAZ-ZZZ TYP S-10 MESSBEREICH: 0 ... 400 PSI
Pressure transmitter for general applications Model S-10 Specifications according data sheet: PE 81.01 Power supply: DC 10 (14) ... 30 V Wetted components: Stainless steel Housing: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 400 psi Process connection: 1/4 NPT Accuracy: 0.5% of span Electrical connection: Angular connector DIN EN 175301-803 A, IP65 permissible fluid temperature: -30 ... + 100 ° C Power supply: 10 ... 30 V DC Occupancy electrical output: UB = 1, 2 = 0V
Elektr. Druckschalter
TECSIS PRESSURE SWITCH 0.2-2 BAR ATT. 1/4
S5301 -4-C1N-ND-B285GZ-ZZ DIAL-T-1AZ2ZZZZZ TYP: S 5301, NENNGROßE 5",
Bimetallic thermometer, Process Industry Series Specifications according data sheet: TM 53.01 Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5301, rotatable nominal size 5 "casing and pivotally Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 300 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 285 mm Window: Instrument glass
S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ
Bimetal thermometer, industrial series Specifications according data sheet: TM 54.01 / 01.15 for TV Twin Temp Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5412, rotatable size 100, housing and pivotally Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: 1/2 NPT Stem diameter: 8 mm Installation length L1: 160 mm Window: Instrument glass Housing: stainless steel Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1
(DIAL T-1AZ1ZZZZZ Bimetal thermometer, industrial series Specifications according data sheet: TM 54.01 / 01.15 for TV Twin Temp Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5412, rotatable size 100, housing and pivotally Design of connection: 2, male nut Unit: ° C Range: 0 ° C ... 80 ° C Process connection: G 1/2 B Stem diameter: 8 mm Installation length L1: 100 mm Window: Instrument glass Housing: stainless steel Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1)
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 317 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 160 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 392 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 160 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 402 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, chemical version Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Display range: -20 ° C ... + 100 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 160 mm Window: Laminated safety glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
claud BIMETAL THERMOMETER, MODEL: S550, NOMINAL SIZE 100, ADJUSTABLE STEM AND DIAL, ACCURACY CLAASS 1 PER EN 13190, SS
(Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 2, male nut Unit: ° C Range: 0 ° C ... 100 ° C Process connection: G 1/2 B Stem diameter: 6 mm Installation length L1: 190 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA)
Diaphragm Seal;Version: Standard; Filling Fluid: Silicone Oil; Coupling: Dist. 3M;AISI 316L diaphragm;AISI 316 process connection;Flange size: 6" ANSI 150 RF;Armored capillary: 3 mt
thermoregulator
MODEL : GA10 INCLUDED DATA ACQUISITION BOARDS , SF6 MOISTURE SENSOR IN CARTRIDGE SF6 PERCENTAGE SENSOR IN CARTRIDGE SO2 SENSOR IN CARTRIDGE CALIBRATION CERTIFICAT AND STD. ACCESSORIES INTERFACE : BLUETOOTH (FRAX-101 ONLY) AND USB WARRANTY 2 YEARS
SN: P074202
membrane
temperature transmitter
(OEM screw-TF35 Measuring range: -50 ... + 250 ° C Measuring element: 1xPt100 / 2-wire connection Tolerance: Class B, DIN EN 60751 Thermowell material: Brass Protective tube diameter [F1 o F2.]: 7.5 mm Process connection [E]: thread G1 / 4B Installation length [U1]: 28 mm Electrical connection: connector AMP Junior Power Timer; Marking: WIKA Packing: plastic bag Data Sheet: TF35 - TE67.10 Customs tariff number: 90251920)
