BRAND | RTK |
Product | PV 6211 for 321062/02 |
Description | pneumatic control valve |
Internal code | ONR4902326 |
Technical specification | Pneumatic control valve - PV 6211 series in continuous form nominal size DN 32, nominal pressure PN 25 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 15 m³/h, stroke 30 mm Seat diameter 32 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C pneumatic actuator - type ST 6135.B6-6G Supply air pressure max. 6 barue Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: port A, mixing valve: port B) |
Discover the superior quality and performance of the RTK PV 6211 for 321062/02 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV 6211 for 321062/02 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV 6211 for 321062/02 :
At Onrion LLC , we offer the PV 6211 for 321062/02 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PV 6211 for 321062/02 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
