BRAND | Georgin |
Product | P/N: 40300, Type: NFA50L |
Description | pressure switch |
Internal code | ONR4450991 |
Custom code | 90322000 |
Technical specification | of the airgas series Case: steel with blue epoxy coating Measuring range: 0 - 250 mbar max. pressure: 3 bar Sensor element: membrane BuNan Material: BuNan - mazak flange process connection: 1/4" GF 2 separate SPDT contacts fixed hysteresis 1./2nd contact: =2.6/8 min./max. setting between 2 SPDT: 33/140 Amperage: 5A/240VAC - 0.5A/130VDC electrical output: cable entry features: standard housing (IP20) Item Code: NAP500LB00000 |
Discover the superior quality and performance of the Georgin P/N: 40300, Type: NFA50L with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N: 40300, Type: NFA50L is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N: 40300, Type: NFA50L :
At Onrion LLC , we offer the P/N: 40300, Type: NFA50L at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the P/N: 40300, Type: NFA50L ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Georgin products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Zener Barriere
Zener diode
range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.
Pressure switch F series
Pressure switch
Pressure switch F series
(Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)
Drucktransmitter
Drucktransmitter
Drucktransmitter
SWITCH PRESSURE
(Pressure switch)
pressure Switch
(Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)
material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000
Druckschalter mit Flansch
Pressure indicator
pressure switch
Manometer
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
