BRAND | ProMinent |
Product | BT4B1604PPT2000UA110A00 |
Description | pump version B |
Internal code | ONR4765554 |
Custom code | 84135040 |
Technical specification | Series: BT4B - BETA 4 - pump version B Pump type: 1604 - 16bar, 3.6l/h ANS.6x4/SS6x5 Dosing head material: PP - polypropylene Seal material: T - standard membrane with PTFE seal. Dosing head design: 2 - with vent, without valve spring Hydraulic connection: 0 - standard connection Version: 0 - GEH.RAL5003/cover RAL2003 Logo: 0 - with PM logo Voltage version: U - Universal 100-240 V Cable and plug: A - 2m Europe Relay function: 1 - Fault alarm relay falling Accessories: 1 - Dos.v.u.Fussv.,2mSchl.5mpe Schl Control type: 0 - without lock Control variant: A - external analog 0-20mA/4-20mA Remote stop: 0 - Pause opener, Niv. openers Auxiliary frequency: 0 - external frequency = 180max Approval: 01 - CE Frequency (Hz): 50/60Hz Voltage (V): 100-230V Power (W): 16.5W Protection class: IP66/NEMA4X Delivery rate (l/h): 3.6l/h Back pressure (bar): 16bar |
Discover the superior quality and performance of the ProMinent BT4B1604PPT2000UA110A00 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BT4B1604PPT2000UA110A00 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BT4B1604PPT2000UA110A00 :
At Onrion LLC , we offer the BT4B1604PPT2000UA110A00 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BT4B1604PPT2000UA110A00 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ProMinent products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
