| BRAND | CD AUTOMATION |
| Product | RC3800-41ABU01011 |
| Internal code | ONR4690819 |
| Technical specification | REVO-C-3PH Nominal current 800A Extrarapid Fixed Fuse Included Maximum load voltage 480V Auxiliary voltage supply range: 90 to 135Vac Input: 4-20 mA Firing: Burst Firing - No Soft Start Control Mode: Voltage No Option 115V fan CE Approved Load Type: Normal Resistive with 3 Phase Delta or Star Connection Communication: No. 1 Modbus RTU - Retransmission 4:20 mA Replacement drive for old drive: MULTIDRIVE 3PH/700A/487A/415V/460V/3D/110V/RE/BF4/V/4-20Ma/10kpot/w420 |
Discover the superior quality and performance of the CD AUTOMATION RC3800-41ABU01011 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The RC3800-41ABU01011 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of RC3800-41ABU01011 :
At Onrion LLC , we offer the RC3800-41ABU01011 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the RC3800-41ABU01011 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply CD AUTOMATION products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Thyristorsteller Serie S (30A@40C; 24A@50C)
regulator heater
SSR Only
CD3000M 2PH/150A/380V/480V/170:265V/SSR/ZC/IF/HB/FAN110V/EM
CD3000M 2 Phases unit 150 Amps / 380V Operating voltage / 480Volts supply voltage 170 to 265 Volts auxiliary power supply SSR Input Zero crossing firing 3 x Internal fuses included Heater Break alarm 110V power supplied fan English Manual
CD3000M 2PH/75A/380V/480V/170:265V/SSR/ZC/NF/HB/110VFAN/EM
CD3000M 2 Phases unit 75 Amps / 380V Operating voltage / 480Volts supply voltage 170 to 265 Volts auxiliary power supply SSR Input Zero crossing firing Without external fuses Heater Break alarm 110V Fan English Manual
44kw CD3000M 3PH
56kw CD3000M 3PH
65kw CD3000M 3PH
CD3000S 1 Phase unit 1PH 45 Amps / Operating voltage not specified / 480V max Voltage 12 to 24 Volts auxiliary power supply SSR Input Zero crossing firing Without external fuses Heater Break alarm with SSR input English Manual
Thyristosteller Serie CD
Scarf Ting; 2 phaser, zero crossing switch
Thyristorsteller Serie S
Current transformer 25A / 0.05A 50-60Hz Ru: 40 ohms Messgenaugikeit: 2% Turns ratio: 500 Temperature range: -40 ... + 70 ° C Connection: flat tabs 6.3mm Dimensions: WxHxD 38x20x48 mm Test voltage pri.-sec .: 4kV Housing: self-extinguishing UL 94-VO incl .: 2x DIN rail adapter for horizontal mounting
CD3200-35A 480V-460V-CL Modular construction consists of: 1x CD3200 drive unit 1xCD3S0035480PA thyristor 1xCD31.CT.50A / 0.05 A current transformer
CD3200-15A-480V-170:265V-0/5V-PA-V-NF-UL
THYRISTOR 240V AC 15A PHASE ANGLE CONTROL 0-5V DC
Thyristor Series CD3000M Type: CD3000M-2 PH-400A-480V-460V-XXX-YYY-HB Configuration (if it is ordered without additional information): XXX: Input 4 ... 20mA YYY: Operating BF8 HB: with partial load failure detection - Alarm relay
Thyristor Series S Type: CD3000S-1PH 35A-480V SSR - Circuit: Einphasensteller, zero crossing switch - Load current: 35 A (T40 ° C), 28A (T50 ° C) - load voltage: up to 480 V - Vdrm: 1200 V - Itsm (10ms): 540 A - I²t (tp = 10 ms): 800 A²s - auxiliary voltage: no - Control: Logic (OFF <1.0 Vdc, ON 3 ... 30 Vdc) 5 Vdc (typ. 14 mA) - Dimensions: 52 x 120 x 120 mm (W) - ideal for heating control with resistive load (zero crossing) - anti-parallel thyristor - CE mark - to save space by integr. heatsink - RC circuit and varistor integrated - LED status indicator - DIN-rail mounting or screw fixing
Thyristor Series S Type: CD3000S-1PH 45A-220V-240V-24VAC-SSR-HB - Circuit: Einphasensteller, zero crossing switch - Load current: 45 A (T40 ° C), 35A (T50 ° C) - load voltage: 240 V - Supply voltage: 24 Vac - Control: Logic (OFF <1 Vdc, ON 5 ... 30 Vdc) - partial load failure: * partial load fault detection from 50 msec. on time * Partial load fault detection from 80% of nominal current * Automatic calibration of the nominal current using a button at 100% control value for about 1 minute - Dimensions: 52 x 120 x 120 mm (W) - ideal for heating control with resistive load (zero crossing) - anti-parallel thyristor - CE mark - to save space by integr. heatsink - RC circuit and varistor integrated - LED status indicator - DIN-rail mounting or screw fixing - incl. Current transformer 50 / 0.05A for DIN rail mounting
Thyristorsteller
Thyristorsteller Serie S Typ: CD3000S-1PH-60A-4BOV-SSR
Thyristirsteller Serie S Typ CD 3000S-2PH-10A-480V SSR
Thyristorsteller S.Nr.: 28469-83122-002
Single-phase thyristor series REVO S, Type: RS1ABCDEFGHIKL
Solid state relays
Single-Thristorsteller series REVO S, Type: RS1ABCDEFGHIKL
