| BRAND | RTK Regeltechnik |
| Product | REact 60E-090 (complete unit) |
| Description | . |
| Internal code | ONR4192903 |
| Custom code | 84818059 |
| Technical specification | Replacement for W.Nr. 15092698/010 -------------- Motorized control valve - MV 5311 series in straight form Nominal size DN 40, nominal pressure PN 25 Housing material nodular cast EN-GJS-400-18-LT Flanges with sealing surface according to DIN Spindle seal: V-seals PTFE / carbon Characteristic curve / inflow: equal percentage / below the cone Parabolic cone, metallic sealing Kvs value = 24 m³ / h, stroke 30 mm Seat diameter 40 mm Surface treatment with zinc dust primer CE marking in accordance with the Pressure Equipment Directive (PED) max.permissible pressure according to DIN EN 1092 max.admissible temperature TS 250 ° C Electric actuator - type REact 60E-090 Adjustment force 6 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.90 mm / s, stroke 30 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) - 1000 Ohm potentiometer |
Discover the superior quality and performance of the RTK Regeltechnik REact 60E-090 (complete unit) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The REact 60E-090 (complete unit) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of REact 60E-090 (complete unit) :
At Onrion LLC , we offer the REact 60E-090 (complete unit) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the REact 60E-090 (complete unit) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
5112570/10 Type MXGBGXXXXXXXXXXXXXXX
proportional valve, dimming speed: 0.44mm / s, 230V 50-60Hz, actuator force 6kN, motor 1500 to 1900 U / min 1.0 Temperature -20C ... 60C output 46VA, IP55, ST # 5113-35 DN 40 and DN 25
Filter element 10micron 065-078-023F
trainer insert with Bypass 062-100-02153
Strainer insert 062-056-02052
About Mobile Terminal switch direction OPEN /
Electrical drive points - type ST 5106-20
electric actuator
POTENTIOMETER FOR ACTUATOR
thermostat
Spare to W.Nr.10062315 / 010 Electric Actuator Force 3.0 kN, including manual adjustment AC motor 230 V, 50/60 Hz Control speed 0.69 mm / s, 15 mm travel Protection IP 65 Column length 280 mm Additional equipment: - additional limit switches (2 pieces) - Potentiometer 200 Ohm - transducer type MU 4524 (2-wire) Output signal: 4..20 mA Effective direction: 0% at the entrance gate to B
Motor
pneumatic actuator
speed : 0,14 mm/sthrust : 6 KN power cons mt :14.7 VA Prot.class : IP 55Temp : -20 C--------60 C Type: MXGBEXXXXXUFGSXXXXXX Voltage 230V 50/60 HZ AC Motor 750/900 U/min 0.68 Actuator options :Positioner : RE3447 Power supply :230V 50/60HZ AC input :4-20 m Aoutput :4-20 mA
Open interface
Open interface
Bonnet
CONE HEAD
CONE SPINDLE
Gasket
Valve FULL TEAM
SEAT RING
Automatic Valve
PNEUMATIC DRIVER
AUTOMATIC VALVE
Digital valve positioner
