BRAND | ProMinent |
Product | Typ RHEP-Pt -SE (150094) |
Description | RH electrode |
Internal code | ONR4502493 |
Custom code | 90278930 |
Technical specification | Redox sensor for use in aqueous media that contain no to a small amount of solids. Applications include process water, drinking water treatment, swimming pools/hot tubs and chemical processes. Redox electrode: platinum Temperature: 0... 80°C max. pressure: 6.0 bar Conductivity: min 150 µS/cm Screw-in thread: PG 13.5 Electrical connection: SN6 (S8) Sensor shaft diameter: 15 mm Installation length: 120 mm Diaphragm: ceramic Electrolyte: gel containing potassium chloride For precise measurements, regular sensor validation with ProMinent quality buffer solutions is recommended! |
Discover the superior quality and performance of the ProMinent Typ RHEP-Pt -SE (150094) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Typ RHEP-Pt -SE (150094) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Typ RHEP-Pt -SE (150094) :
At Onrion LLC , we offer the Typ RHEP-Pt -SE (150094) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the Typ RHEP-Pt -SE (150094) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply ProMinent products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
305096 -PH -Elektrode PHEX-112-SE
pH electrode
Solid electrolyte-filled pH combination electrode with glass shaft Annular gap. Typical application: waste water, drinking water, and industrial water, process chemistry, Emulsions, suspensions. pH range: 1..12 Terminal / thread: SN6 / PG 13.5 Temperature / pressure: 0..100 degrees C / max. 6..16 bar at least conductivity. 500 micro S / cm Installation length: 120 +/- 3mm Order number: 305096
PH Sensor
Sensor
pH electrode
Solid electrolyte-filled pH combination electrode with glass shaft Annular gap. Typical application: waste water, drinking water, and industrial water, process chemistry, Emulsions, suspensions. pH range: 1..12 Terminal / thread: SN6 / PG 13.5 Temperature / pressure: 0..100 degrees C / max. 6..16 bar at least conductivity. 500 micro S / cm Installation length: 120 +/- 3mm
Pneumatic dosing pump PNDb Series: PNDb Pneumados B - B Pump Version Pump type 1601 16 bar, 1 l / h, Conn. 6x4 Dosing head: SS stainless steel Seal material: T standard Membr./ PTFE sealing. Dosing head: 0 o.Entlüftung, o.Ventilfeder Hydraul. connection: 0 standard connection Design (logo): 0 with PM Logo Power outlet: 0 terminal G1 / 4, air pressure 6 bar Control Type / Anst: 0 single acting (Standard) Admission: 01 CE Air pressure: 6 BAR Flow rate: 1.0L / H
Absorption Basket Strainer
Absorption Basket Strainer
RH electrode
ORP sensor
1002534 RH -Elektrode RHER-Pt -SE
ORP sensor
pH probe
Diaphragm Metering Pump max. 120 L/h @ max. 4 bar
Sigma 1 Base Type: S1Ba Sigma 1 base type Engine type: H Main power Pump type: 04120 4 bar, 120 l / h Dosing head: PV PVDF Sealing material: T PTFE seal Positive displacement element: S S. membrane rupture indicator opti. Dosing head: 0 o.Überströmventil, o.Ventilf. Hydraulic Conn: 7 nights Mother &. S-spout PVDF Version: 0 With PM-Logo Electrical connection: S 3ph. 230 / 400V 50 / 60Hz (WBS) Motor version: 0 IP55 (Standard) ISO class F Stroke sensor: 0 No stroke sensor Auto Hublängeneins. 0 stroke length manually Admission: 01 CE Frequency: 50 / 60Hz Voltage: 230 / 400V Power: 0.09KW Protection: IP55 Flow rate: 120 / 144l / h Back pressure: 4 bar
Series: S1CB Sigma Control Type 1 Version B Engine type: H Main power Pump type: 04084 4 bar, 101 l / h Dosing head: PV PVDF Sealing material: T PTFE seal Positive displacement element: S multi-layer membrane opt. Ad Dosing head: 0 o.Entlüftung, o.Ventilf. Hydraulic Conn: 0 Standard Version: 0 With PM-Logo El. Spannungsversorg: U 1ph, 100-240V, 50 / 60Hz, 110W Cables and connectors: A 2m Europe Relay function: 0 without relay Control variant: 1 Manual + Cont + p.c. + Analog + Dos.pr. Overpressure shutdown: 0 without overpressure shutdown Operating unit: S HMI (0.5m cable) Access Code: 1 m. Zugangskontr. Ü.-awake. dyn. Languages: English EN Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-240V Power: 110W Protection: IP65 Flow rate: 101l / h Back pressure: 4 bar
Identcode: S1CBH12017PVTS110UA110S0DE Series: S1CB Sigma Control Type 1 Version B Engine type: H Main power Pump type: 12017 12 bar, 21 l / h Dosing head: PV PVDF Sealing material: T PTFE seal Positive displacement element: S multi-layer membrane opt. Ad Dosing head: 1 o.Entlüftung, m.Ventilf. Hydraulic Conn: 1 O Mother &. E-Part PVC Version: 0 With PM-Logo El. Spannungsversorg: U 1ph, 100-240V, 50 / 60Hz, 110W Cables and connectors: A 2m Europe Relay Function: 1 fail safe relay (Leistungsrel.) Control variant: 1 Manual + Cont + p.c. + Analog + Dos.pr. Overpressure shutdown: 0 without overpressure shutdown Operating unit: S HMI (0.5m cable) Access code:. 0 o Zugangskontr. Ü.-awake. dyn. Languages: DE German Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-240V Power: 110W Power: 110W Protection: IP65 Flow rate: 21l / h Back pressure: 12bar
SUCTION TUBE F. DOSING TANK, 25 METERS ROLL 1004509
D 8x5 mm PE, max. 10bar
TENSION ROD, CONE VALVE, DOUBLE DIAPHRAM,DIAPHRAM HOLDING SCREW, DIAPHRAM DISTANCE DISK (FOR PROMINE
generator
Dulcometer dosing pump, 12,3 lt/h 1,5 bar
dosing pump, 4,4l/h ,10 bar
